Taiwan Semiconductor Bridge Rectifier 400 V 400 A 4-Pin Single GBPC3504W T0

Taiwan Semiconductor GBPC3504W T0 Bridge Rectifier 400 V 400 A 4-Pin Single is a discrete semiconductor designed to efficiently convert alternating current (AC) to direct current (DC). The bridge rectifier circuit utilizes four diodes arranged in a bridge configuration to provide consistent polarity output regardless of AC input polarity.

This device supports high current transmission with a forward current rating of 35A and can sustain peak surge currents up to 400A, making it suitable for demanding power conversion applications. Its robust thermal handling with a maximum operating temperature up to 150°C allows reliable operation in various industrial and electronic environments.

The through-hole mount design with a GBPC package type and 4-pin configuration supports easy assembly on printed circuit boards (PCBs). The bridge rectifier features isolated voltage from case to lead exceeding 2500V for enhanced safety and electrical isolation.

Its compact dimensions (29 mm length and width, 11.23 mm height) enable integration into limited space applications. The device exhibits a peak forward voltage drop of 1.1V and an extremely low peak reverse current leakage of 5μA, ensuring efficiency and minimal energy losses.

Applications for this bridge rectifier include industrial equipment power supplies, electronic motor controls, HVAC systems, battery charging circuits, and other commercial or manufacturing processes requiring stable DC power conversion.

The GBPC35W series Bridge Rectifiers are well-regarded for their durability, thermal management due to an integrally molded heat sink, and isolation capabilities tailored for high-performance demanding electronics.

The bridge rectifier is designed for converting AC input to DC output in electronic circuits. It features a high peak reverse repetitive voltage of 400V suitable for power applications. Supports continuous forward current up to 35A with surge capacity up to 400A.

Through-hole mounting with GBPC package type and 4-pin configuration for ease of PCB assembly. Includes thermal protection with maximum operating temperature rated to 150°C. Low leakage current and forward voltage drop ensure operational efficiency.

Compact dimensions facilitate integration into various electronic devices. Ideal for use in industrial, manufacturing, and commercial electronic power circuits.

This product is in new condition and made in India or sourced typically from Taiwan Semiconductor manufacturing standards. It complies with industrial quality without specific automotive standards or certifications.
