Taiwan Semiconductor Bridge Rectifier, 600 V 300 A, 4-Pin Single GBPC1506

Taiwan Semiconductor GBPC1506 Bridge Rectifier 600 V 300 A 4-Pin Single is a high-performance discrete semiconductor designed for power conversion applications in electronics and electrical systems. This bridge rectifier efficiently converts alternating current (AC) input into direct current (DC) output, providing reliable electrical rectification for various industrial and commercial uses.

The GBPC1506 series from Taiwan Semiconductor features a screw mount type and GBPC package configuration, making installation and integration into power circuits straightforward. With a single-phase design and 4-pin configuration, this device is engineered for optimal electrical performance in compact form factors.

Key electrical characteristics include a peak reverse repetitive voltage (VRRM) of 600 volts and a continuous forward current rating of 15 amperes, suitable for moderate power handling requirements. The rectifier can handle peak non-repetitive forward surge currents up to 300 amperes, allowing it to withstand transient electrical surges during operation.

The device operates reliably within a wide temperature range from -50°C up to 150°C, suitable for demanding environments and extended reliability. Its glass passivated chip junction design assures enhanced durability and thermal stability.

The physical dimensions of 29 mm length, 29 mm width, and 11.23 mm height support space-constrained applications while providing good thermal dissipation through an integrally molded heat sink. The low peak forward voltage of 1.1 V reduces power losses during conduction, enhancing circuit efficiency.

This bridge rectifier is ideal for use in industrial electronics, power supplies, HVAC controls, motor control circuits, instrumentation, and other electrical systems requiring stable and efficient AC to DC conversion. Its high-level isolation voltage of over 2500 V from case to lead ensures excellent safety and noise immunity in electrical systems.

Operates with a peak reverse repetitive voltage of 600 V. Capable of sustaining a continuous forward current of 15 A. Supports surge currents up to 300 A for transient conditions. Compact 4-pin GBPC package with screw mount type.

Wide operating temperature range from -50°C to 150°C. Glass passivated chip junction for durability and stability. Low peak forward voltage of 1.1 V for efficient conduction. Isolated voltage over 2500 V enhances safety and noise immunity.

This product is certified for UL E-96005 approval, ensuring compliance with safety and quality standards. Explore more semiconductor components and Bridge Rectifiers in the Electronics & Electricals category on EnvMart for your industrial and commercial electronic needs.
