Molex Right Angle Surface PCB Header, 8 Contacts, 3 mm Pitch, 2 Row, Shrouded 43045-0809

Molex 43045-0809 Right Angle Surface PCB Header is a high-performance connector designed for demanding electronic and industrial applications. This PCB header provides 8 contacts arranged in two rows with a standard 3 mm pitch, ensuring compact device configurations and tight space usage. Constructed with a high temperature thermoplastic housing and brass tin-plated contacts, this connector is built for durability and reliable electrical performance.

The shrouded design enhances safety by preventing accidental contact, while the right angle orientation simplifies connections on PCBs where vertical space is limited. Rated for a maximum current of 8.5 A and supporting voltages up to 600 V, this header suits power connections in automation systems and various wire-to-board electronic configurations. It operates within a temperature range from -40°C to +105°C and withstands soldering temperatures up to 260°C compatible with lead-free processes.

With a mating pin length of 3 mm and designed to endure up to 30 mating cycles, it provides dependable mechanical and electrical connections over extended use. The 94V-0 flammability rating further ensures compliance with safety standards for industrial and consumer electronics. It mates seamlessly with Molex 43025 Micro-Fit 3.0™ receptacles, offering design flexibility for integrators.

This PCB header is ideal for use in industrial automation, consumer electronics, and manufacturing equipment where compact, secure, and reliable connectors are essential. Its surface mount design with solder termination ensures ease of assembly and robust mechanical retention on PCBs, supporting a recommended PCB thickness of 1.6 mm.

Constructed with high temperature thermoplastic housing for durability. Dual-row, right angle shrouded design optimizes PCB layout space. Brass contacts with tin plating ensure corrosion resistance. Surface mount with solder termination suitable for 8.5A current rating.

Operates between -40°C and 105°C; supports soldering at 260°C. Complies with 94V-0 flammability rating for safety. Compatible with 43025 Micro-Fit 3.0™ receptacles. Suitable for automation, consumer electronics, and industrial equipment.

Designed for up to 30 mating cycles for sustained reliability. Explore more precision PCB Headers and electronic components within Molex’s range on EnvMart to enhance your industrial and commercial projects.
