Molex SL Series Right Angle Through Hole PCB Header, 5 Contacts, 2.54 mm Pitch, 1 Row, Shrouded 70553-0039

The Molex 70553-0039 SL Series Right Angle Through Hole PCB Header is a high-quality connector designed for industrial and electronic applications requiring reliable wire-to-board connections. This model features 5 male contacts arranged in a single row with a precise 2.54 mm pitch and a right-angle orientation, making it suitable for compact PCB layouts.

The connector housing is molded from high temperature thermoplastic that enhances durability and withstands harsh operating conditions. Its phosphor bronze contacts are plated with tin to provide excellent electrical conductivity and resistance to corrosion, suitable for sustaining a continuous current of 3A at 250V.

The through hole mount type with solder termination facilitates secure attachment to printed circuit boards, and the 3.3 mm tail pin length ensures robust solder joints. Operating temperature range from -40°C to 105°C adds versatility for various environments, including industrial, manufacturing, and electronic assembly sectors.

This shrouded PCB header design protects the pins from damage and reduces the risk of accidental short circuits, thus enhancing overall reliability and user safety. The connector mates with Molex 70066G and 70066N series housings, making it a flexible choice for multiple connector configurations.

5 male contacts in a single row with 2.54 mm pitch. Right angle orientation for compact PCB design. High temperature thermoplastic housing for enhanced durability. Phosphor bronze contact material with tin plating for excellent conductivity.

3A current rating and 250V voltage rating for demanding applications. Through hole mounting with solder termination type. Operating temperature range: -40°C to 105°C. Shrouded design protects contacts and prevents shorts.

Manufactured in the United States ensuring high quality.

This component is ideal for electronics manufacturing, industrial equipment, and laboratory devices that require rugged and dependable PCB connections. Available in tubes for production line efficiency, the Molex 70553-0039 PCB Header supports seamless integration with compatible housings and connectors.
