Molex SL Series Right Angle Through Hole PCB Header, 3 Contacts, 2.54 mm Pitch, 1 Row, Shrouded 70553-0037

Molex 70553-0037 SL Series Right Angle Through Hole PCB Header features a compact 1-row, 3-contact configuration with a 2.54 mm pitch. This shrouded header is constructed using high temperature thermoplastic housing, ensuring durability and performance in demanding environments. Its phosphor bronze contacts are plated with tin, providing reliable conductivity and corrosion resistance.

Designed for wire-to-board connections, this header mounts via through-hole technology with a right-angle orientation, suitable for space-constrained PCB layouts. It supports a current rating of 3A and voltage rating of 250V, operating safely in ambient temperatures ranging from -40°C to 105°C.

This connector mates typically with Molex 70066G and 70066N series housings, making integration within related components straightforward. The male contact gender and 3.3 mm tail pin length facilitate secure solder termination. The product is manufactured in the United States under Molex's SL Series specifications, known for quality and compatibility in industrial and electronic assemblies.

Widely used in electronics, power, and connector component assemblies, this PCB header is suitable for applications requiring reliable electrical connections with compact form factors. Ideal for industrial equipment, laboratory instrumentation, communication devices, and manufacturing systems.

Shrouded single-row PCB Header for robust connector protection. 3 contacts with 2.54 mm pitch enable standard wire-to-board connections. High temperature thermoplastic housing ensures stability under heat stress. Phosphor bronze contacts with tin plating provide corrosion resistant conductivity.

Right angle orientation for efficient PCB space utilization. Rated for 3A current and 250V voltage in circuits. Wide operating temperature range from -40°C to 105°C. Manufactured in the United States ensuring quality standards compliance.
