Texas Instruments Operational Amplifier 5.5 MHz 5.5 V PDIP 8-Pin OPA340PA

Texas Instruments OPA340PA is a high-performance operational amplifier designed for precise analog signal processing in electronic circuits. Featuring a gain bandwidth product of 5.5 MHz and an 8-pin PDIP package, this device supports through-hole mount applications where reliability and ease of integration are important.

It operates on a supply voltage ranging from 3 V to a maximum of 5.5 V, providing flexibility for low voltage designs. With a high slew rate of 6 V/μs, the amplifier delivers fast response times for dynamic signal environments.

The OPA340PA is characterized by a low input offset voltage of ±500 microvolts along with very small input bias and offset currents, making it suitable for sensitive and precision measurement systems.

This CMOS-based operational amplifier supports a wide temperature range from -40°C up to 85°C, ensuring stable operation in diverse environmental conditions. Its dimensions (9.81 mm length, 6.35 mm width, and 4.57 mm height) make it compact to fit into space-constrained PCB layouts.

The package is designed without specific automotive certifications but caters effectively to general industrial and electronic signal amplification applications including instrumentation, control systems, and analog signal processing.

This operational amplifier supports a supply voltage range from 3 V to 5.5 V. It offers a high slew rate of 6 V/μs for fast response. The input offset voltage is low at ±500 μV ensuring accurate amplification. Input bias current and offset current are extremely low at ±10 pA, suitable for precision applications.

Operates reliably over a wide temperature range from -40°C to 85°C. The amplifier has a compact size with dimensions 9.81 mm in length, 6.35 mm in width, and 4.57 mm in height. The single-channel CMOS device comes without specific automotive standards.

Ideal for electronic circuit designs requiring stable and precise signal amplification. The PDIP package type provides ease of manual or automated PCB assembly.

This product is an essential component for industrial electronics, laboratory instrumentation, manufacturing equipment, and educational purposes where stable analog amplification is required.
