Panasonic ECHU(X) 1.2 nF 50V dc 50V ac Surface Film Capacitor ECHU1H122GX5

Panasonic ECHU1H122GX5 is a high-quality film capacitor designed for use in electronic components and power connectors applications. It features a 1.2 nF capacitance and is rated for 50V DC and 50V AC voltage. This surface mount capacitor is constructed from stacked metallised PPS film and offers a mold-less design that enhances its electrical characteristics.

Its compact size with dimensions of 2 mm length, 1.25 mm width, and 0.9 mm height enables effective integration into densely packed circuits. The capacitor supports reflow soldering processes, making it compatible with modern surface-mount technology (SMT) production. With a maximum operating temperature of 125°C, it offers excellent thermal stability for reliable operation in demanding environments.

This capacitor is characterized by a low equivalent series resistance (ESR), enhancing filtering and resonance circuit functions. Panasonic’s ECHU(X) series components conform to RoHS standards, ensuring compliance with environmental regulations.

Applications include time-constant circuits, oscillation, resonance filtering, and audio applications in various industrial, commercial, and electronic device manufacturing sectors. The capacitor’s lightweight and compact form factor is ideal for space-sensitive PCB designs, supporting efficient and durable electronic assemblies.

Constructed from stacked metallised PPS film providing high reliability. Compact and lightweight design suitable for modern electronics. Reflow soldering compatible for SMT assembly processes. Rated for a maximum operating temperature of 125°C.

Low equivalent series resistance (ESR) for better performance. Ideal for time-constant, oscillation, resonance, filtering, and audio circuit applications. Compliance with RoHS standards ensuring environmental safety. Dimensions: 2 mm length, 1.25 mm width, and 0.9 mm height for space-efficient PCB layouts.

This product supports industrial, electronics manufacturing, laboratory and research equipment, and commercial electronics applications. Panasonic’s ECHU1H122GX5 film capacitor ensures high performance, durability, and compliance for reliable electronic designs.
