TDK Surface Mount Common Mode Line Filter with Ferrite Core 300mA Idc 2520 Package ACM2520-601-2P-T
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | TDK |
| Height | 1.2mm |
| Length | 2.5mm |
| Model | ACM2520-601-2P-T |
| Depth | 2mm |
| Packaging | Reel |
| Series | ACM |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -25°C |
| Interfaces | USB and IEEE1394 computer lines, LVDS panel link lines |
| Core Material | Ferrite |
| Standards/Approvals | RoHS |
| Package/Case | 2520 |
| Maximum DC Current | 300mA |
| Pin Count | 2 |
| Maximum DC Resistance | 450mΩ |
| Termination Style | Wire |
| Inductor Construction | Wirewound |
| TDK, Signal FilterBrand | TDK |
| CHOKE SMD 2 LINE X 0.3RBrand | TDK |
Key Features
- This surface mount common mode line filter uses a ferrite core to suppress radiation and common-mode noise effectively.
- It features a wirewound inductor construction ensuring minimal impact on high-speed differential signals.
- The device has a maximum DC resistance of 450mΩ, suitable for compact electronics applications.
- Operating temperature ranges from -25°C to +85°C for reliable performance in various environments.
- Commonly applied for USB, IEEE1394 computer lines, and LVDS panel link lines for noise suppression.
- The product is RoHS compliant and comes in a reel packaging, enabling efficient automated assembly.
- Designed and manufactured in Japan, ensuring high-quality standards and durability.
Product Description
TDK ACM2520-601-2P-T is a Surface Mount Common Mode Line Filter designed with a Ferrite Core and wirewound inductor construction, rated for a maximum DC current of 300mA. Housed in a compact 2520 SMD package, it measures 2.5mm in length, 1.2mm in height, and 2mm in depth, making it suitable for space-constrained electronic designs.
This filter provides common-mode impedance greater than 1000Ω at 100MHz and maintains low differential mode impedance ensuring minimal effect on high-speed data signals. It operates reliably within a temperature range of -25°C to +85°C, suitable for automotive and consumer electronic environments.
Applications include radiation and common-mode noise suppression in USB and IEEE1394 computer data lines, as well as LVDS panel link lines, enhancing signal integrity. The device is RoHS compliant and packaged on a reel to support streamlined manufacturing processes.
This surface mount common mode choke is miniature and suitable for high-frequency noise suppression. Wirewound construction provides stable inductance and low resistance. Compact 2520 package allows easy integration in dense PCBs.
Rated maximum DC current: 300mA, providing adequate capacity for typical signal-line filtering. Operating temperatures from -25°C to +85°C guarantee performance under varied thermal conditions. Core material: ferrite ensures excellent magnetic properties for noise filtration.
2-pin wire termination style for surface mounting on printed circuit boards.
Manufactured in Japan, this TDK ACM Series line filter meets high-quality engineering standards suitable for industrial, consumer electronics, automotive, and telecommunications applications. It supports reliable EMI and signal noise reduction essential for sensitive electronic systems.
