TDK Chassis Mount EMC Filter 20 A 250V AC 50Hz, 60Hz Screw Termination Single Phase B84112G0000G120



Category EMC Filter Brand TDK Condition New

Specifications

Country of Origin	China
Brand	TDK
Height	43mm
Length	52mm
Model	B84112G0000G120
Depth	135mm
Mount Type	Chassis Mount
Operating Frequency	50, 60Hz
Series	B84112G
Maximum Operating Temperature	100°C
Number Of Stages	1
Capacitance	2pF
Minimum Operating Temperature	-25°C
Maximum Current	20A
Number of Phases	1
Leakage Current	369μA
Maximum Voltage	250V ac
Inductance	2mH
Standards/Approvals	UL 1283
Termination Style	Screw

Key Features

Compact chassis mount design allows easy installation in electronic systems.
Screw termination style ensures secure and reliable electrical connections.
Comprises a single stage with capacitance of 2pF and inductance of 2mH for effective EMI suppression.
Operates reliably within temperature range from -25°C to 100°C.
Features compliance with UL 1283 safety standard for EMI filters.
Leakage current rating of 369μA suitable for industrial and telecom applications.
Constructed with metal casing for durability and enhanced insertion loss performance.
Ideal for use in industrial electronics, switch-mode power supplies, telecom and data systems.

Product Description

TDK B84112G0000G120 is a high-performance chassis mount EMC filter engineered for single phase electronic systems operating at 50Hz and 60Hz frequencies. Rated at a maximum current of 20 A and a voltage of 250V AC, this filter provides effective suppression of electromagnetic interference in demanding industrial environments.

The filter features a screw termination style for robust and secure electrical connection and a compact metal case design which facilitates easy chassis mounting. The product is constructed with two line filters in a single stage configuration, offering a capacitance of 2pF and an inductance of 2mH to efficiently reduce conducted noise.

Designed for consistent performance across a broad temperature range from -25°C to 100°C, the filter meets UL 1283 standards ensuring safety and reliability in critical applications. Its leakage current rating of 369μA supports sensitive electronic equipment by minimizing electrical leakage.

This EMC filter is suited for multiple industrial applications including industrial electronics, switch-mode power supplies, telecom systems, data communication, DC applications, and medical equipment (special version B84112G0000M*).

Compact chassis mount design allows easy installation in electronic systems. Screw termination style ensures secure electrical connections. Single stage with 2pF capacitance and 2mH inductance for EMI suppression. Temperature operating range from -25°C to 100°C ensures reliability.

Complies with UL 1283 for safety and performance. Low leakage current of 369μA suitable for sensitive electronics. Durable metal casing enhances performance and longevity. Wide industrial applicability including power supplies and telecom.

Manufactured in China with quality assurance.

The TDK B84112G0000G120 EMC filter is an essential component for engineers seeking to ensure electromagnetic compatibility and minimize interference in their electronic designs. Explore EnvMart's comprehensive catalog for more EMC Filtering solutions to meet diverse industrial and commercial requirements.
