Vishay 40 V 200 mA Surface Mount Schottky Diode Quadro Melf LS103A-GS08
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 1.5mm |
| Length | 3.5mm |
| Model | LS103A-GS08 |
| Width | 1.7mm |
| Mount Type | Surface |
| Series | LS103A |
| Maximum Operating Temperature | 125°C |
| Package Type | Quadro Melf |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 200mA |
| Peak Reverse Repetitive Voltage Vrrm | 40V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 5μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 15A |
| Maximum Forward Voltage Vf | 1.2V |
| Peak Reverse Recovery Time trr | 10ns |
Key Features
- Single diode configuration with low forward voltage drop for efficient switching performance.
- Quadro MELF package ensures compact, surface-mount design with height 1.5 mm and length 3.5 mm.
- Maximum forward voltage of 1.2 V and peak reverse recovery time of 10 ns for fast diode action.
- Wide operating temperature range from -65°C to 125°C suitable for demanding industrial environments.
- Meets AEC-Q101 automotive standard for quality and reliability in vehicle electronics.
- Peak non-repetitive forward surge current rating of 15 A ensures robustness under transient conditions.
- Extremely low peak reverse current of 5 μA reduces leakage losses and improves efficiency.
- Ideal for power rectification in electronic circuits, power management, and fast switching applications.
Product Description
Vishay LS103A-GS08 is a high-performance Schottky diode designed for industrial and automotive electronic applications. This surface mount diode supports a peak reverse voltage of 40 V and continuous forward current of 200 mA, making it suitable for low power rectification and fast switching circuits.
The diode is housed in a compact Quadro MELF package measuring 3.5 mm in length, 1.7 mm in width, and 1.5 mm in height, facilitating efficient PCB layout and space savings in complex assemblies.
With a maximum forward voltage of 1.2 V and a very fast peak reverse recovery time of 10 ns, the LS103A-GS08 minimizes power loss and electromagnetic interference, enhancing system efficiency.
Operating over a broad temperature range from -65°C to 125°C and compliant with the AEC-Q101 automotive standard, this diode is well-suited for harsh industrial and automotive environments.
Single diode configuration with low forward voltage drop for efficient switching performance. Quadro MELF package ensures compact, surface-mount design with height 1.5 mm and length 3.5 mm. Maximum forward voltage of 1.2 V and peak reverse recovery time of 10 ns for fast diode action.
Wide operating temperature range from -65°C to 125°C suitable for demanding industrial environments. Meets AEC-Q101 automotive standard for quality and reliability in vehicle electronics. Peak non-repetitive forward surge current rating of 15 A ensures robustness under transient conditions.
Extremely low peak reverse current of 5 μA reduces leakage losses and improves efficiency. Ideal for power rectification in electronic circuits, power management, and fast switching applications.
This diode is commonly used in industrial equipment, automotive power electronics, telecommunications, consumer electronics, and laboratory instrumentation. Its fast switching capabilities and low power loss make it an excellent choice for power rectifiers and protection circuits.
Explore the complete range of Schottky diodes and discrete semiconductor components at EnvMart for reliable electronic component sourcing.
Explore more products in our Semiconductors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum reverse voltage rating of the Vishay LS103A-GS08 Schottky diode is 40 V.
This model supports a continuous forward current of up to 200 mA.
The peak non-repetitive forward surge current rating is 15 A.
The diode is housed in a Quadro MELF package.
The dimensions of the diode are 3.5 mm in length, 1.7 mm in width, and 1.5 mm in height.
It operates over a wide temperature range from -65°C to 125°C.
The maximum forward voltage drop for this diode is 1.2 V.
The peak reverse recovery time is 10 ns, allowing for fast switching performance.
This diode meets the AEC-Q101 automotive standard for quality and reliability.
The peak reverse current is rated at 5 μA, which helps reduce leakage losses.
The LS103A-GS08 features a single diode configuration.
It is commonly used in industrial equipment, automotive power electronics, telecommunications, and consumer electronics.
