Texas Instruments Schmitt Trigger Input Inverter Logic IC 3 Elements 8-Pin US6 Package SN74LVC3G14DCUR

Texas Instruments SN74LVC3G14DCUR is a low-voltage CMOS logic inverter IC with Schmitt Trigger input functionality. It has 3 inverter elements integrated into an 8-pin US6 surface-mount package, making it ideal for compact and efficient electronic circuit applications.

Operating within a voltage range of 1.65 to 5.5 volts, this IC offers compatibility with LVTTL/TTL inputs and LVCMOS outputs. It delivers fast switching capabilities with a propagation delay as low as 9.7 nanoseconds, supporting the requirements of digital signal conditioning and logic inversion.

The device can handle maximum output currents of -32 mA (high level) and 32 mA (low level), suitable for driving standard bus loads. It operates reliably over a temperature range of -40°C to 125°C, offering robustness for demanding industrial and commercial electronic systems.

The compact package dimensions of 2.1 mm length, 2.4 mm width, and 0.8 mm height allow integration into dense PCB layouts. The US6 surface mount type ensures easy automated assembly and space savings.

Contains 3 Schmitt Trigger input inverters for precise signal conditioning. Supports operating voltages from 1.65 V to 5.5 V for versatile logic levels. Propagation delay of 9.7 ns ensures high-speed operation. Compact 8-pin US6 surface mount package for space-efficient PCB design.

Wide operating temperature range (-40°C to 125°C) suitable for industrial use. Compatible with input LVTTL/TTL and output LVCMOS logic families. Supports max output currents of -32 mA (high) and 32 mA (low) for reliable driving capability.

Dimensions: 2.1 mm x 2.4 mm x 800 μm for small form factor applications.

This inverter IC is extensively used in electronic devices, embedded systems, industrial automation, and signal processing where reliable logic level inversion and noise immunity are critical. It is suitable for PCB assemblies requiring low power consumption and high switching speeds.
