Molex Zero-Hachi Series Right Angle Surface PCB Header, 2 Contact(s), 0.8 mm Pitch, 1 Row, Shrouded 214721-0020
Specifications
| Country of Origin | Korea |
|---|---|
| Brand | Molex |
| Orientation | Right Angle |
| Current | 1A |
| Mount Type | Surface |
| Housing Material | Thermoplastic |
| Contact Material | Copper Alloy |
| Series | Zero-Hachi |
| Termination Type | Surface Mount |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -20°C |
| Number of Rows | 1 |
| Pitch | 0.8mm |
| Standards/Approvals | RoHS, UL |
| Contact Plating | Matt Tin |
| Number of Contacts | 2 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Mating Pin Length | 2mm |
Key Features
- Features a right angle orientation for space-saving PCB mounting.
- Constructed with thermoplastic housing for durability and electrical insulation.
- Supports a current rating of 1A per contact.
- Equipped with copper alloy contacts plated with matt tin for corrosion resistance.
- Designed for surface mount termination type enhancing assembly efficiency.
- Operates reliably between -20°C and 105°C temperature range.
- The connector system provides robust PCB retention and breakage protection.
- Includes mating pin length of 2 mm for secure connections.
Product Description
Molex 214721-0020 Zero-Hachi Series Right Angle Surface PCB Header is a precision engineered wire-to-board connector with a 0.8 mm pitch, designed for compact and reliable PCB applications.
This shrouded, single-row header contains 2 contacts with right angle orientation to optimize PCB space and enable slim device designs.
Constructed with thermoplastic housing and copper alloy contacts plated with matt tin, it offers high durability and excellent electrical performance suitable for industrial and electronics manufacturing environments.
Rated at 1A current capacity per contact, the header supports surface mount termination, providing efficient and secure PCB assembly. It reliably operates within a temperature range from -20°C to 105°C, delivering stable performance under varied conditions.
The dual-point contact design ensures superior mating retention and electrical contact reliability, protecting against connector breakage during wiring stress.
Compliant with RoHS and UL standards, this connector meets strict environmental and safety requirements, making it suitable for industrial electronics, communication equipment, and embedded system designs.
Manufactured in the Republic of Korea, this header ensures consistent quality and precision manufacturing. Features a right angle orientation for space-saving PCB mounting. Constructed with thermoplastic housing for durability and electrical insulation.
Supports a current rating of 1A per contact. Equipped with copper alloy contacts plated with matt tin for corrosion resistance. Designed for surface mount termination type enhancing assembly efficiency. Operates reliably between -20°C and 105°C temperature range.
The connector system provides robust PCB retention and breakage protection. Includes mating pin length of 2 mm for secure connections. Meets RoHS and UL standards ensuring environmental and safety compliance. Manufactured in Republic of Korea.
Explore more high-quality PCB connectors and headers in the Electronics & Electricals category at EnvMart to support your electronic design and manufacturing projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a current rating of 1A per contact.
The pitch size of this header is 0.8 mm.
It operates reliably between -20°C and 105°C.
This model contains 2 contacts.
The housing is made of thermoplastic, and the contacts are made of copper alloy plated with matt tin for corrosion resistance.
It is designed for surface mount termination type, enhancing assembly efficiency.
This model features a right angle orientation for space-saving PCB mounting.
Yes, it is compliant with RoHS and UL standards, ensuring environmental and safety compliance.
The mating pin length is 2 mm, providing secure connections.
This header is manufactured in the Republic of Korea.
It utilizes a wire-to-board connector system, which is suitable for various applications.
This model has 1 row.
