Vishay 150 V 35 A Surface Mount Rectifier & Schottky Diode TO-252 3-Pin DPAK V35PWM15HM3/I
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 13in |
| Brand | Vishay |
| Height | 1.3mm |
| Length | 6.1mm |
| Model | V35PWM15HM3/I |
| Width | 6.1mm |
| Mount Type | Surface |
| Series | eSMP |
| Maximum Operating Temperature | 175°C |
| Package Type | TO-252 |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | RoHS |
| Pin Count | 3 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 35A |
| Peak Reverse Repetitive Voltage Vrrm | 150V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 9mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 260A |
| Maximum Forward Voltage Vf | 1.4V |
Key Features
- Utilizes trench MOS Schottky technology for low forward voltage drop and high efficiency.
- Features a compact TO-252 surface mount package with a low profile height of 1.3 mm.
- Designed for maximum continuous forward current of 35 A and peak reverse repetitive voltage of 150 V.
- Operates safely at high temperatures up to 175°C and supports peak surge current of 260 A.
- Suitable for automated placement and applications such as DC/DC converters, freewheeling diodes, and polarity protection.
- Complies with RoHS standards and is AEC-Q101 automotive qualified for reliability in automotive systems.
Product Description
Vishay V35PWM15HM3/I is a high current density surface-mount rectifier and Schottky Diode featuring trench MOS Schottky technology. This device has a surface mount TO-252 (DPAK) package with 3 pins and a minimal height of 1.3 mm, making it suitable for compact electronics assemblies.
This diode supports a maximum continuous forward current of 35 A and a peak reverse repetitive voltage rating of 150 V, operating reliably up to 175°C. It provides a maximum forward voltage of 1.4 V and can handle a peak non-repetitive forward surge current of 260 A, ensuring high robustness.
The Vishay V35PWM15HM3/I is designed to meet industry standards including RoHS and automotive AEC-Q101 qualification, ensuring compliance and reliability in automotive and industrial environments.
The diode is ideal for use in low voltage, high frequency DC/DC converters, freewheeling diodes in switching power supplies, and polarity protection circuits, supporting efficient power management in industrial, automotive, and commercial electronics.
Trench MOS Schottky technology for low forward voltage drop and efficiency. Compact TO-252 (DPAK) surface mount package, suitable for automated manufacturing. Maximum continuous forward current of 35 A and peak reverse repetitive voltage of 150 V.
High operating temperature tolerance up to 175°C and surge current capability of 260 A. RoHS compliant and AEC-Q101 automotive qualified for stringent quality standards.
Vishay products are well-established in the electronics industry for their quality and performance. Browse additional semiconductor and diode products on EnvMart to find complementary components for your designs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current for this model is 35 A.
This diode has a peak reverse repetitive voltage rating of 150 V.
The height of the TO-252 package is 1.3 mm.
It operates safely at a maximum temperature of 175°C.
The maximum forward voltage drop for this diode is 1.4 V.
The peak non-repetitive forward surge current rating is 260 A.
This model complies with the AEC-Q101 automotive standard.
The diode has a length and width of 6.1 mm each.
Yes, this diode is RoHS compliant.
It is suitable for applications such as DC/DC converters, freewheeling diodes, and polarity protection circuits.
The minimum operating temperature for this diode is -40°C.
This diode utilizes surface mount technology.
