Infineon N-Channel Power MOSFET 40 V 212 A 81 W SuperSO8 5x6 Surface Mount BSZ063N04LS6ATMA1
Specifications
| Country of Origin | India |
|---|---|
| Brand | Infineon |
| Model | BSZ063N04LS6ATMA1 |
| Mount Type | Surface |
| Series | BSZ |
| Maximum Operating Temperature | 175°C |
| Package Type | SuperSO8 5 x 6 |
| Minimum Operating Temperature | -55°C |
| Standards/Approvals | RoHS |
| Pin Count | 8 |
| Channel Type | N |
| Maximum Continuous Drain Current Id | 212A |
| Maximum Drain Source Voltage Vds | 40V |
| Maximum Drain Source Resistance Rds | 0.7mΩ |
| Channel Mode | N |
| Maximum Power Dissipation Pd | 81W |
| Typical Gate Charge Qg @ Vgs | 80nC |
| Maximum Gate Source Voltage Vgs | 20V |
| Forward Voltage Vf | 1V |
Key Features
- Features low on-resistance of 0.7 milliohms to minimize conduction losses.
- Supports maximum power dissipation of 81 W for heavy-duty applications.
- Operates across a wide temperature range from -55°C to 175°C.
- Typical gate charge is 80 nC for precise and efficient switching control.
- Gate-source voltage limit is 20 V to protect device integrity.
- RoHS compliant, suitable for environmentally sensitive designs.
- Ideal for high-current DC-DC converters and synchronous rectification in server power rails.
- Designed for surface mount assembly with 8-pin SuperSO8 package.
Product Description
Infineon BSZ063N04LS6ATMA1 is an N-channel power MOSFET optimized for compact surface-mount assemblies requiring high current handling and low conduction losses. The device boasts a maximum continuous drain current of 212 A and a maximum drain-source voltage rating of 40 V, making it suitable for medium-voltage power switching applications in industrial and commercial electronics.
Its low on-resistance of 0.7 milliohms reduces conduction losses significantly, enabling efficient power management. The MOSFET supports power dissipation up to 81 W and operates reliably over a broad temperature range from -55°C to 175°C, ensuring robust performance in harsh environments.
The typical gate charge of 80 nC enables predictable and energy-efficient switching behaviour, while the maximum gate-source voltage of 20 V protects against over-voltage stress. The device complies with RoHS directives, aligning with environmental regulations.
Common applications include high-current DC-DC converters, synchronous rectifiers in server power supplies, motor driver circuits requiring sturdy surface-mount switches, and battery management systems handling substantial electrical loads. The 8-pin SuperSO8 5x6 package allows for efficient surface mounting on printed circuit boards, ideal for compact electronic designs.
Low on-resistance of 0.7 milliohms minimizes conduction losses. Supports continuous drain current of 212 A for heavy current loads. Max power dissipation of 81 W facilitates high-power switching. Wide operating temperature range from -55°C to 175°C ensures reliability.
Typical gate charge of 80 nC enables effective switching control. Maximum gate-source voltage limited to 20 V to ensure device safety. RoHS compliant for environmental safety. Compact 8-pin SuperSO8 5x6 surface mount package.
This product is suited for industrial electronics, power management, telecommunications, automotive electronics (non-automotive certified), data centers, and other applications demanding reliable, high-performance switching elements. Browse EnvMart for more Infineon semiconductor products and MOSFET components tailored for precise electronic circuit needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous drain current for this model is 212 A, making it suitable for heavy current loads in various applications.
This power MOSFET supports a maximum power dissipation of 81 W, facilitating high-power switching applications.
It operates over a wide temperature range from -55°C to 175°C, ensuring reliable performance in harsh environments.
The typical gate charge is 80 nC, which enables effective and efficient switching control.
The maximum gate-source voltage is limited to 20 V to protect the device from over-voltage stress.
It is designed in an 8-pin SuperSO8 5x6 surface mount package, suitable for compact electronic designs.
Yes, this model is RoHS compliant, aligning with environmental regulations for safe use in sensitive designs.
Common applications include high-current DC-DC converters, synchronous rectifiers in server power supplies, and motor driver circuits.
The on-resistance is 0.7 milliohms, which minimizes conduction losses and enhances efficiency.
The forward voltage for this MOSFET is 1 V, which is relevant for specific circuit configurations.
This model features an N-channel configuration, suitable for various switching applications.
The country of origin for this product is India.
