onsemi 1.56 V Zener Diode Single 300 mW Surface Mount 3-Pin SOT-23 BZX84C5V6ET3G

onsemi BZX84C5V6ET3G is a high-quality Zener diode designed for voltage regulation in electronic circuits requiring precision and reliability. This single-element Zener diode supports a nominal Zener voltage of 5.6 volts and can dissipate up to 300 mW of power, making it suitable for low-power voltage stabilizing applications. The device is housed in a compact surface-mount SOT-23 package with three pins, allowing easy integration into modern PCB layouts.

With an operating temperature range from -65°C to 150°C, the Zener diode ensures stable operation across broad environmental conditions, ideal for industrial, consumer electronics, and automotive applications. The maximum Zener impedance of 40 ohms guarantees consistent voltage regulation, while the maximum reverse leakage current of 1 microampere prevents unwanted current flow when reverse biased.

Test current for the diode is standardized at 5 mA, ensuring accuracy in voltage regulation parameters. The typical voltage temperature coefficient of 2.5 mV/K reflects how the voltage varies predictably with temperature changes, aiding precise circuit designs.

This diode complies fully with RoHS environmental directives, confirming its safe usage with restricted hazardous substances. The small footprint and SOT-23 packaging allow utilization in compact electronics, including industrial control systems, telecommunications equipment, and power management circuits.

Applications include use as a voltage regulator, electrical noise suppression, and transient voltage protection in circuit designs requiring compact and reliable components. Its robust environmental ratings make it ideal for manufacturing, laboratory instrumentation, and automotive electronics.

Choose the onsemi BZX84C5V6ET3G Zener diode for dependable voltage regulation in your next electronics design. Explore similar semiconductor components and electronics parts to complement your circuit assembly needs at EnvMart.

This diode is configured as a single element for voltage regulation applications. Nominal Zener voltage is 5.6 volts with a maximum power dissipation of 300 mW. It features a compact SOT-23 package with 3 pins for surface mounting.

Operating temperature ranges from -65°C minimum to 150°C maximum. Maximum Zener impedance is 40 Ω ensuring stable voltage characteristics. Maximum reverse leakage current is 1 μA providing low leakage performance. Test current is rated at 5 mA for Zener voltage measurement.

The device complies with RoHS standards, assuring environmental safety. The package dimensions are 3.04 mm length and 1.11 mm height for PCB design considerations. Typical voltage temperature coefficient is 2.5 mV/K. Browse the EnvMart semiconductor catalog for additional Zener Diode and voltage regulation components by onsemi and other leading manufacturers.
