Microchip 10-Bit 2-Channel SPI Digital to Analogue Converter, 8-Pin PDIP MCP4812-E/P

Microchip MCP4812-E/P is a 10-bit resolution, 2-channel Digital to Analogue Converter (DAC) packaged in an 8-pin PDIP standard through-hole format. It features resistor string DAC architecture with an internal voltage reference, providing stable and accurate analog output voltages. The device communicates via SPI interface, making it compatible with a wide range of microcontrollers and industrial control systems.

Operating over a supply voltage range of 2.7V to 5.5V, the MCP4812-E/P supports operation in extreme temperature conditions ranging from -40°C to 125°C, suitable for industrial, automation, and embedded applications. The DAC offers a rapid settling time of 4.5 microseconds, enabling quick updates of output voltages in time-sensitive processes.

Its compact physical size (10.1mm length, 7.1mm width, 5.3mm height) and 8-pin PDIP package facilitate easy integration into through-hole circuit boards and prototypes. This makes the product ideal for use in industrial instrumentation, laboratory equipment, control systems, and electronic design development.

The DAC's two independent output channels allow for simultaneous generation of two different analog voltage outputs, facilitating multi-channel analog control and signal generation.

It is RoHS compliant and designed without specific automotive standards, making it suitable primarily for general industrial and electronic component applications. Provides 10-bit resolution for precise analog output voltage control.

Contains two independent output channels for versatile applications. Operates with a supply voltage range from 2.7V to 5.5V. Interfaces with microcontrollers via standard SPI protocol. Designed for through-hole mounting with an 8-pin PDIP form factor.

Features fast settling time of 4.5 microseconds for quick signal transitions. Suitable for operating temperatures from -40°C to 125°C ensuring reliability in harsh environments. Compact size with dimensions approximately 10.1mm length, 7.1mm width, and 5.3mm height.

Outputs analog voltage signals suitable for control and measurement systems. Manufactured in Thailand maintaining high quality standards.

Suitable for industrial instruments, embedded system development, automated control systems, and precision measurement applications. Explore the full range of electronic components and semiconductors available at EnvMart for your project needs.
