Broadcom Miniature 500ppr Optical Encoder 5V DC TTL Output HEDS-8903
Specifications
| Country of Origin | India |
|---|---|
| Brand | Broadcom |
| Model | HEDS-8903 |
| Overall Width | 170mm |
| Overall height | 7.1mm |
| Overall Depth | 14.3mm |
Key Features
- Provides 2 digital output waveforms 90° out of phase for resolution and direction detection.
- The 3 channel version includes an index pulse per revolution for enhanced versatility.
- Operates at 5V DC with TTL compatible digital outputs.
- Supports operating temperature range from -40°C to +100°C suitable for varied environments.
- Compact design with overall dimensions of 170mm width, 14.3mm depth, and 7.1mm height.
- Connection is via plug-in cable assemblies available separately.
- Ideal for precise motion control applications requiring incremental position feedback.
- Designed for use in industrial automation and control systems.
Product Description
Broadcom HEDS-8903 Optical Encoder is a precise miniature hollow shaft encoder designed for fitting directly onto motor shafts and similar rotating equipment. It produces 500 pulses per revolution (ppr), providing accurate incremental position feedback essential for motion control applications in industrial automation, manufacturing, robotics, and related sectors.
This encoder features 2 digital output waveforms shifted 90 degrees out of phase, enabling both resolution and rotational direction detection. Additionally, the 3 channel variant includes an index pulse once per revolution, adding versatility for synchronization and positioning tasks.
The encoder operates at 5V DC and offers TTL-compatible outputs, ensuring compatibility with a wide range of control electronics. It supports an extended operating temperature range from -40°C to +100°C, making it suitable for demanding environments.
With compact overall dimensions of 170mm width, 14.3mm depth, and 7.1mm height, this device integrates easily into tight spaces. Connections are facilitated through plug-in cable assemblies, which are sold separately, allowing flexible installation options.
This optical encoder is well-suited for industrial use cases such as manufacturing automation, robotics, motor feedback control, and any application requiring high-resolution incremental position sensing.
Provides 2 digital output waveforms 90° out of phase for resolution and direction detection. The 3 channel version includes an index pulse per revolution for enhanced versatility. Operates at 5V DC with TTL compatible digital outputs.
Supports operating temperature range from -40°C to +100°C suitable for varied environments. Compact design with overall dimensions of 170mm width, 14.3mm depth, and 7.1mm height. Connection via plug-in cable assemblies available separately.
Ideal for precise motion control in industrial automation and robotics. Explore more Motion Control Sensors and optical encoders at EnvMart, your trusted source for industrial automation components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The HEDS-8903 provides 500 pulses per revolution (ppr), allowing for accurate incremental position feedback.
It operates at 5V DC, providing TTL-compatible digital outputs for compatibility with various control electronics.
The encoder supports an operating temperature range from -40°C to +100°C, making it suitable for varied environments.
This model has overall dimensions of 170mm in width, 14.3mm in depth, and 7.1mm in height.
It features 2 digital output waveforms that are 90° out of phase, enabling both resolution and rotational direction detection.
The HEDS-8903 is ideal for precise motion control applications in industrial automation, manufacturing, and robotics.
Yes, the 3 channel version includes an index pulse per revolution, enhancing versatility for synchronization and positioning tasks.
Connections are made via plug-in cable assemblies, which are sold separately, allowing for flexible installation options.
The TTL output ensures compatibility with a wide range of control electronics, facilitating integration into various systems.
The country of origin for this encoder is India.
Its primary function is to provide incremental position feedback for motion control applications, essential for accurate control in various systems.
