Semikron Danfoss Bridge Rectifier Module, 1600 V 750 A, 7-Pin Single SKB 72/16

Semikron Danfoss SKB 72/16 Bridge Rectifier Module is a high-performance power semiconductor device designed for converting alternating current (AC) to direct current (DC) in industrial and electronic applications. This module delivers a peak reverse repetitive voltage rating of 1600 V and supports a forward current of 150 A, making it suitable for heavy-duty power conversion requirements.

The SKB 72/16 module features a 7-pin single configuration and comes with an isolated metal case fitted with screw terminals, facilitating easy and secure chassis mounting. Its compact dimensions - 72 mm length, 42 mm width, and 30 mm height - allow seamless integration into existing power assemblies.

Engineered for durability, it operates within a temperature range of -40°C to 150°C, catering to demanding industrial environments including automation, power supplies, and semiconductor equipment. The device offers a peak non-repetitive forward surge current of 750 A, ensuring resilience under transient surge conditions.

With a low peak forward voltage of 1.6 V, the bridge rectifier maximizes electrical efficiency, reducing power losses significantly. This makes it an essential component for high-current rectification tasks requiring reliable performance and long-term stability.

Manufactured in Italy, the module meets high quality and reliability standards though it does not carry specific certifications. It is supplied with mounting hardware to facilitate installation. Its application scope ranges across industrial electronics, laboratory power setups, HVAC control systems, and manufacturing automation.

The module features a 7-pin single configuration optimized for chassis mounting. Operates efficiently with forward current rating of 150 A and peak surge current of 750 A. Equipped with an isolated metal case with screw terminals for easy mounting and heat dissipation.

Constructed to withstand maximum operating temperature of 150°C and minimum of -40°C for versatile industrial applications. Dimensions are compact at 72 mm length, 42 mm width, and 30 mm height for easy integration. Designed with a peak reverse repetitive voltage of 1600 V ensuring high voltage endurance.

Peak forward voltage drop is low at 1.6 V, maximizing efficiency in power conversion. Ideal for industrial electronics, power supply circuits, semiconductor applications, and automation systems. Manufactured in Italy with robust build quality and compliance-focused design standards.
