| Country of Origin | China |
|---|---|
| Brand | HY Electronic Corp |
| Height | 2.42mm |
| Length | 4.6mm |
| Model | ES1G |
| Width | 2.9mm |
| Mount Type | Surface |
| Series | ES1A THRU ES1J |
| Maximum Operating Temperature | 150°C |
| Package Type | DO-214AC (SMA) |
| Minimum Operating Temperature | -55°C |
| Polarity | Cathode |
| Standards/Approvals | UL 94V-0 |
| Pin Count | 2 |
| Maximum Continuous Forward Current If | 1A |
| Peak Reverse Repetitive Voltage Vrrm | 400V |
| Diode Configuration | Single |
| Rectifier Type | Fast Recovery |
| Peak Reverse Current Ir | 5μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 30A |
| Maximum Forward Voltage Vf | 1.3V |
| Peak Reverse Recovery Time trr | 35ns |
| Case Plastic material | UL flammability classification 94V-0 |
HY Electronic Corp ES1G is a fast recovery Schottky diode designed for surface mount applications requiring high speed and efficient power rectification. It features a maximum continuous forward current of 1 ampere and can withstand a peak reverse repetitive voltage of up to 400 volts. The device is housed in a compact DO-214AC (SMA) package that facilitates easy integration onto printed circuit boards.
This diode offers a low maximum forward voltage drop of 1.3 volts, enhancing energy efficiency by reducing losses during conduction. With a peak reverse recovery time of only 35 nanoseconds, it ensures minimal switching delays making it suitable for high frequency switching applications.
The ES1G diode is rated for operation in a wide temperature range from -55°C to 150°C, enabling reliable performance in diverse industrial and commercial environments. Its low peak reverse current of 5 microamperes minimizes leakage currents, thereby improving overall circuit stability.
The plastic case material adheres to UL flammability classification 94V-0, delivering superior flame retardant properties for safer operation. The diode configuration is single with two pins, where the cathode is clearly indicated for correct polarity connection.
Surface mount technology for compact electronic assemblies. Fast recovery Schottky diode with high current capacity. Low forward voltage drop for efficiency enhancement. Wide operating temperature range for industrial reliability.
Compliance with UL 94V-0 flame retardant standard. Compact form factor with precise dimensional specifications. Ideal for power supply circuits, voltage clamping, and switching regulators.
This diode is particularly suited for industrial electronics, power supplies, automotive electronics, telecommunications equipment, and other high-speed switching applications requiring robust and efficient rectification. Its compact size facilitates use in densely populated PCB designs, contributing to miniaturization efforts in electronic device manufacture.
