Texas Instruments Operational Amplifier 4-Channel 3 MHz Gain Bandwidth Product 14-Pin 15V PDIP TL074CN
Specifications
| Country of Origin | India |
|---|---|
| Brand | Texas Instruments |
| Height | 5.08mm |
| Length | 10.16mm |
| Model | TL074CN |
| Width | 6.6mm |
| Mount Type | Through Hole |
| Series | TL074 |
| Maximum Operating Temperature | 70°C |
| Package Type | PDIP |
| Minimum Operating Temperature | 0°C |
| Number Of Channels | 4 |
| Pin Count | 14 |
| Maximum Supply Voltage | 15V |
| Minimum Supply Voltage | 5V |
| GBP - Gain Bandwidth Product | 3MHz |
| Input Bias Current | 7 nA |
| Vos - Input Offset Voltage | 13 mV |
| Slew Rate | 13V/μs |
| Input Offset Current | 10 nA |
Key Features
- Features a gain bandwidth product of 3 MHz suitable for medium-frequency amplification.
- Operates within voltage ranges from 5V minimum to 15V maximum supply voltage.
- Equipped with low input offset voltage of 13 mV and input bias current of 7 nA.
- Provides a slew rate of 13 V/μs enabling fast response times in analog circuits.
- Designed with 14 pins in a PDIP package compatible with through-hole mounting techniques.
- Operates reliably from 0°C to 70°C ensuring stable performance in typical environmental conditions.
- Input offset current is maintained at a low 10 nA to reduce signal errors.
Product Description
Texas Instruments TL074CN operational amplifier is a high-performance, low-noise, quad-channel amplifier designed for various electronic applications requiring stable and precise amplification. Featuring a gain bandwidth product of 3 MHz, it enables effective signal processing in laboratory, industrial, and electronic circuit environments.
The device supports a supply voltage ranging from 5V to 15V, allowing flexibility for multiple power configurations. Its low input offset voltage of 13 mV and minimal input bias and offset currents ensure accurate signal amplification with reduced errors. The 13 V/μs slew rate facilitates swift signal changes, making TL074CN suitable for medium-speed analog applications.
Packaged in a 14-pin Plastic Dual Inline Package (PDIP), this operational amplifier is compatible with through-hole PCB mounting, simplifying installation and maintenance. It operates reliably within standard ambient temperature ranges of 0°C to 70°C, suitable for most commercial and industrial environments.
The package dimensions of 10.16 mm length, 6.6 mm width, and 5.08 mm height make the component compact and convenient for compact circuit layouts. The TL074 series is known for its low noise and low distortion characteristics, making this model an ideal choice for audio amplifiers, sensor signal conditioning, and general-purpose operational amplifier tasks.
Gain bandwidth product of 3 MHz. Low input offset voltage and bias currents for precision amplification. Wide supply voltage range from 5V to 15V. Slew rate of 13 V/μs suitable for medium speed analog circuits. Compatible with through-hole mounting via 14-pin PDIP package.
Operating temperature range from 0°C to 70°C for stable performance. Compact packaging dimensions for flexible PCB design.
This Texas Instruments TL074CN is ideally suited for electronic component laboratories, manufacturing circuits, audio amplification systems, and other commercial or industrial electronic instrumentation where reliable operational amplifier performance is essential.
Browse more Operational Amplifiers at EnvMart to find the perfect fit for your next project.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The TL074CN operational amplifier features a gain bandwidth product of 3 MHz, suitable for medium-frequency amplification.
It operates within a supply voltage range from 5V minimum to 15V maximum, allowing flexibility for various power configurations.
This model is a quad-channel operational amplifier, meaning it has 4 channels for amplification.
The input offset voltage is 13 mV, which helps in achieving precision amplification with reduced signal errors.
The TL074CN has a slew rate of 13 V/μs, enabling fast response times in analog circuits.
The package dimensions are 10.16 mm in length, 6.6 mm in width, and 5.08 mm in height, making it compact for circuit layouts.
It is packaged in a 14-pin Plastic Dual Inline Package (PDIP), which is compatible with through-hole mounting techniques.
This operational amplifier operates reliably within a temperature range of 0°C to 70°C.
The input bias current is 7 nA, which contributes to its low noise performance.
It is suitable for applications such as audio amplification, sensor signal conditioning, and general-purpose operational tasks.
The input offset current is maintained at a low 10 nA, further reducing signal errors during amplification.
This model is designed for through-hole mounting, making it easy to install on PCBs.
