HY Electronic Corp 100 V 1 A Surface Mount Schottky Diode 2-Pin DO-214AC SS110

HY Electronic Corp SS110 Schottky Diode is a high-performance 2-pin diode housed in a compact DO-214AC surface mount package designed for discrete semiconductor applications. Rated for a maximum continuous forward current of 1 ampere and a peak reverse repetitive voltage of 100 volts, it achieves efficient rectification with a low forward voltage drop of 850 mV, attributed to its Schottky barrier construction.

Constructed with an epitaxial design and metal-semiconductor junction featuring guarding technology, this diode ensures improved switching speed and reduced power loss. It supports a wide operating temperature range from -55°C up to 150°C, making it suitable for industrial, automotive, and consumer electronic environments requiring durable semiconductor components.

The diode’s compact physical dimensions (4.6 mm length, 2.9 mm width, and 2.41 mm height) facilitate design flexibility on densely populated PCBs. Encased in a molded plastic package conforming to UL 94V-0 flammability standards, it offers enhanced safety by resisting ignition.

Additional robustness is provided by its peak non-repetitive forward surge current of 30 A, enabling it to withstand transient current spikes commonly seen during switching or fault conditions. Polarity is clearly marked with a cathode band for straightforward installation.

This diode is ideal for use in free-wheeling diode circuits, inverter circuits, and polarity protection across a range of electronics, power management, and industrial semiconductor applications.

Maximum continuous forward current of 1 A for reliable load handling. Peak repetitive reverse voltage of 100 V ensures effective blocking capability. Low forward voltage drop reduces power dissipation and heat generation.

Compact surface mount DO-214AC package aids circuit integration. Wide operating temperature range from -55°C to 150°C for diverse applications. Robust 30 A surge current tolerance enhances transient protection. Flame-retardant molded plastic case with UL 94V-0 rating for safety.

Polarity indicated by cathode band simplifies assembly and maintenance. Schottky barrier design improves switching efficiency and performance. Explore HY Electronic Corp components for reliable semiconductor solutions in your industrial, commercial, and electronic design projects through EnvMart.
