Fujitsu Through Hole Signal Relay 9V DC Coil Voltage 1A Switching Current DPDT Contact Configuration RY-9W-K

Fujitsu RY-9W-K through hole signal relay is designed for industrial and electronic automation applications requiring reliable switching with a 9V DC coil voltage and 1A switching current. Its DPDT (Double Pole Double Throw) contact configuration makes it versatile for control and signal switching tasks on printed circuit boards using through-hole mounting.

The relay provides switching voltage capabilities of up to 120V AC and 60V DC and a switching power of 24W, suitable for various low-power switching needs. Its gold-plated contacts ensure minimal contact resistance, delivering long-lasting and stable electrical performance even under frequent switching operations.

The compact dimensions of 20.2mm length, 12.5mm height, and 9.8mm width allow for efficient PCB layout and integration in sophisticated electronic devices. Coil power consumption is low at 150mW with a coil resistance of 540Ω, contributing to energy efficient relay actuation.

Operating temperature range from -30°C to 90°C accommodates various industrial environments, from cold to hot conditions. The unit is sealed with a plastic body offering high dielectric strength and surge resistance up to 1,500 volts, ensuring durability and protection from electrical disturbances.

This relay complies with RoHS environmental directives, supporting sustainable manufacturing standards. The solder terminal type facilitates secure mechanical and electrical connections during assembly.

The coil power consumption is 150mW ensuring energy efficiency. It offers switching capability up to 120V AC and 60V DC for versatile use. Constructed with gold-plated contacts to ensure reliability and low contact resistance of 100mOhm.

Operates reliably from -30°C up to 90°C for a wide temperature range. The relay body measures 20.2mm length, 12.5mm height, and 9.8mm width for compact PCB mounting. Designed for through-hole mounting with solder terminals for strong connections.

Coil resistance is 540 Ohms providing stable coil operation. Surge strength specification at 1,500 V enhances electrical durability. Meets RoHS standards ensuring environmental compliance. Manufactured in Japan ensuring quality and performance.

This Fujitsu Signal Relay is ideal for industrial, laboratory, manufacturing, and automation control applications where reliable signal switching is critical. It supports a range of electronic and electrical systems requiring durable and precise relay operation. Choose Fujitsu relays for trusted performance in critical signal conditioning circuits.
