Eaton 800mA T Ceramic Cartridge Fuse 5 x 20 mm 400V DC Time Delay S505H-800-R
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 400V dc |
| Diameter | 5mm |
| Brand | Eaton |
| Body Material | Ceramic |
| Model | S505H-800-R |
| Overall Length | 20mm |
| Current Rating | 800mA |
| Series | S505H |
| Maximum Operating Temperature | +85°C |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | PSE, TUV, CCC, cURus, IEC 60127-2 |
| Fuse Characteristics | Time Delay |
| Fuse Size | 5 x 20 mm |
| Application Category | Time Delay |
Key Features
- The fuse features a ceramic body for enhanced thermal stability.
- It has a T-speed time-delay characteristic to mitigate nuisance blows from inrush currents.
- Rated at 800mA current and 5 x 20 mm fuse size.
- Suitable for industrial automation control modules and power supply protection.
- Operates reliably between -40°C and +85°C, supporting a wide temperature range.
- Approved to IEC 60127-2 and multiple international standards including PSE, TUV, CCC, and cURus.
Product Description
Eaton S505H-800-R Ceramic Cartridge Fuse 800mA 5 x 20 mm is designed for dependable time-delay overcurrent protection in DC electrical and electronic assemblies up to 400V. The ceramic construction ensures excellent thermal resistance and mechanical integrity under thermal stress, making it ideal for harsh industrial environments.
This fuse's T-speed time-delay characteristic allows for controlled surge absorption, protecting low-current circuits against overloads without nuisance blows caused by inrush currents. With a fuse size of 5 x 20 mm and a current rating of 800mA, it is well-suited for use in industrial automation control modules, power supplies, sensors, and motor control electronics protection during startup operations.
The S505H-800-R is qualified for continuous operation within the temperature range of -40°C to +85°C, with some sources indicating operation capacity from -55 °C to +125 °C, supporting severe conditions in field installations.
It holds multiple international safety and quality certifications, including PSE, TUV, CCC, cURus, and complies with the IEC 60127-2 standard for miniature fuses. These approvals confirm its suitability for global applications in industrial, electrical, automation, and instrumentation sectors.
The fuse features a robust ceramic body for enhanced thermal performance. Time-delay (T-speed) characteristic minimizes nuisance trips during inrush currents. Current rating of 800mA protects low-current DC circuits effectively.
Compact 5 x 20 mm fuse size fits standard cartridge fuse holders. Approved to international standards ensuring cross-market compatibility and safety. Set contains 1 Pc Eaton S505H-800-R Ceramic Cartridge Fuse.
Suitable for use in industrial automation, electrical panels, DC-powered instrumentation, and sensor protection applications. The fuse is an essential component for safeguarding electrical circuits from sustained faults while tolerating brief surges.
Explore more reliable fuses and circuit protection devices in the Electronics & Electricals category on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Eaton S505H-800-R fuse has a current rating of 800mA.
This fuse is rated for a maximum voltage of 400V DC.
The fuse has a diameter of 5mm and an overall length of 20mm.
It operates reliably within a temperature range of -40°C to +85°C.
This model features a time-delay characteristic to mitigate nuisance blows from inrush currents.
The fuse features a ceramic body, which provides enhanced thermal stability and mechanical integrity.
It is approved to multiple international standards including PSE, TUV, CCC, cURus, and IEC 60127-2.
It is suitable for use in industrial automation control modules, power supplies, sensors, and motor control electronics protection.
The time-delay feature allows for controlled surge absorption, protecting low-current circuits against overloads without nuisance trips.
The fuse belongs to the S505H series.
Yes, its ceramic construction ensures excellent thermal resistance and mechanical integrity under thermal stress, making it ideal for harsh industrial environments.
The package contains 1 piece of the Eaton S505H-800-R Ceramic Cartridge Fuse.
