DiodesZetex Small Signal NPN Transistor 100 mA 45 V 6-Pin SOT-363 BC847BS-7-F

DiodesZetex BC847BS-7-F is a small signal NPN transistor designed primarily for surface-mounted applications in a 6-pin SOT-363 package. With a maximum DC collector current of 100 mA and a collector emitter voltage rating of 45 V, this transistor offers reliable switching performance for various electronic devices and circuits.

The device features a high transition frequency of 300 MHz, enabling fast switching speeds suitable for high-frequency applications. It supports a power dissipation of 200 mW, ensuring operation under moderate power conditions without thermal stress.

The transistor's operational temperature span from -65°C to 150°C makes it ideal for both industrial and automotive electronics, complying with the automotive standard AEC-Q101. The minimum DC current gain (hFE) of 200 provides adequate amplification for signal processing tasks.

Compact and lightweight, the BC847BS-7-F transistor measures just 3 mm in length, 2.5 mm in width, and 1.1 mm in height. Its surface mount technology (SMT) package allows for efficient PCB real estate utilization in manufacturing high-density circuit boards.

This device is commonly used in industrial, automotive, consumer electronics, and communication equipment applications for amplification and switching purposes. Maximum DC collector current: 100 mA. Maximum collector emitter voltage: 45 V.

Transition frequency: 300 MHz. Power dissipation: 200 mW. Operating temperature range: -65°C to 150°C. Package: 6-pin SOT-363 surface mount. Conforms to AEC-Q101 automotive quality standard. Polarity: NPN transistor. Explore the comprehensive range of discrete semiconductors and Bipolar Transistors available at EnvMart to support your electronic design and manufacturing needs.
