Vishay Switching Diode, Single, Silicon Junction, 500 mA, Surface Mount DO-213AA Package, 800 V, 1.3 V Forward RGL34K-E3/98

Free Delivery in India | Lowest Global Shipping Charges

Vishay Switching Diode, Single, Silicon Junction, 500 mA, Surface Mount DO-213AA Package, 800 V, 1.3 V Forward RGL34K-E3/98

Name: Vishay Switching Diode, Single, Silicon Junction, 500 mA, Surface Mount DO-213AA Package, 800 V, 1.3 V Forward RGL34K-E3/98
Brand: Vishay
SKU: 218089
Price: 0.37 USD
Availability: InStock



Category Switching Diode Brand Vishay Condition New

Specifications

Country of Origin	India
Diameter	1.67mm
Brand	Vishay
Height	1.68mm
Length	3.68mm
Model	RGL34K-E3/98
Width	1.68mm
Mount Type	Surface
Maximum Operating Temperature	175°C
Case	DO-204AL, molded epoxy over glass body
Package Type	DO-213AA
Sub Type	Silicon Junction
Minimum Operating Temperature	-65°C
Polarity	Color band denotes cathode end
Terminals	Matte tin plated leads, solderable per
Pin Count	2
Diode Configuration	Single
Peak Non-Repetitive Forward Surge Current Ifsm	10A
Maximum Forward Voltage Vf	1.3V
Peak Reverse Recovery Time trr	250ns
Maximum Forward Current If	500mA
Maximum Peak Reverse Repetitive Voltage Vrrm	800V

Key Features

This diode features a DO-213AA package suitable for surface mounting.
It has a maximum forward voltage of 1.3 V and supports a maximum forward current of 500 mA.
Fast recovery time of 250 ns enhances switching efficiency in electronic circuits.
Operates reliably between -65°C and 175°C operating temperature range.
Color band on the diode body indicates cathode polarity for easy identification.
Glass passivated junction with superectifier structure ensures high reliability and low leakage current.
Matte tin plated leads are solderable following J-STD-002 and JESD 22-B102 standards.
Suitable for snubber circuits in camera flashes and high voltage rectification in CRT and TV grids.

Product Description

Vishay RGL34K-E3/98 switching diode is a high-reliability single silicon junction diode packaged in a compact DO-213AA surface mount case. Rated for 500 mA continuous forward current and a maximum peak reverse voltage of 800 V, it is ideal for efficient fast switching applications in electronic and power circuits.

Featuring a 1.3 V maximum forward voltage drop and a fast peak reverse recovery time of 250 ns, this diode optimizes performance in switching environments such as snubber circuits in camera flash units and high voltage rectification in G2 grids of CRT and television sets.

The device operates reliably over a wide temperature range, from -65°C minimum to 175°C maximum operating temperature, ensuring stable performance in demanding industrial and commercial applications.

The diode’s superectifier structure and cavity-free glass-passivated junction provide a low leakage current, typically less than 0.2 μA, enhancing device efficiency and longevity. The terminals are matte tin plated for superior solderability compliant with industry standards J-STD-002 and JESD 22-B102, while the epoxy molded glass body meets UL 94 V-0 flammability requirements.

A clearly marked color band indicates the cathode end for correct polarity installation. The RGL34K-E3/98 is RoHS-compliant, fulfilling modern environmental standards. Typical industrial use cases include power management in consumer electronics, automation equipment, and laboratory electronics requiring reliable high voltage switching diodes.

This diode features a DO-213AA package suitable for surface mounting. Maximum forward current rating of 500 mA for continuous operation. Peak reverse voltage rating of 800 V suitable for high voltage applications. Fast switching time reduces switching losses and improves circuit efficiency.

Low leakage current enhances performance and reduces power loss. Molded epoxy case designed for durability and flammability safety standard UL 94 V-0. Matte tin plated leads ensure good solderability under recognized standards.

Color band marking for cathode polarity ensures ease of installation. Suitable for use in CRTs, TVs, camera flashes, and other electronic switching circuits. Explore more Vishay Switching Diodes and related semiconductor components on EnvMart for diverse industrial and laboratory applications.
