| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 1.35mm |
| Length | 2.85mm |
| Model | MMSZ5242B-G3-08 |
| Mount Type | Surface |
| Series | MMSZ5242 |
| Maximum Operating Temperature | 150°C |
| Package Type | SOD-123 |
| Minimum Operating Temperature | -65°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Maximum Power Dissipation Pd | 500mW |
| Diode Configuration | Single |
| Test Current It | 20mA |
| Maximum Reverse Leakage Current | 1μA |
| Nominal Zener Voltage Vz | 12V |
| Zener Type | Small Signal |
| Maximum Zener Impedance | 30Ω |
Vishay MMSZ5242B-G3-08 is a 1.12 volt nominal Zener diode designed for surface mounting using a compact SOD-123 2-pin package. This small signal diode is capable of dissipating up to 500 milliwatts, making it suitable for precise voltage regulation in low power circuits.
With a Zener voltage tolerance of ±5%, it ensures consistent voltage stabilization and has a maximum impedance of 30 ohms at the standard test current of 20 mA. The device features a maximum reverse leakage current of only 1 microampere, which helps maintain circuit efficiency.
Its temperature operating range from -65°C to 150°C allows use in various industrial, laboratory, and commercial electronics applications requiring robust environmental tolerance. The diode's compact design with a height of 1.35 mm and length of 2.85 mm aids in space-saving PCB layouts and efficient surface mounting assembly processes.
Typical applications include use in power supplies, voltage reference circuits, and protection circuits in electronic devices across industrial automation, instrumentation, and communication equipment.
This diode has a nominal Zener voltage of 12 volts with ±5% tolerance for stable voltage reference. Maximum power dissipation of 500 mW supports low power circuit protection. SOD-123 package type designed for surface mount technology provides reliable mechanical mounting.
Maximum reverse leakage current of 1 μA reduces power loss in circuits. Operating temperature from -65°C to 150°C ensures performance in harsh conditions. Maximum Zener impedance of 30 ohms stabilizes output voltage under test current.
Single diode configuration for small signal voltage regulation applications. No automotive standard compliance; intended for general industrial use. Compact physical dimensions: 1.35 mm height, 2.85 mm length. Explore the full range of semiconductor diodes and electronic components for your projects on EnvMart.
