Samtec CLP Series Straight Surface PCB Socket 14-Contact 2 Row 1.27 mm Pitch 340V CLP-107-02-G-D
Specifications
| Country of Origin | United States |
|---|---|
| Voltage | 340V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 3.4A |
| Model | CLP-107-02-G-D |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Bronze |
| Series | CLP |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Board-to-Board |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 1.27mm |
| Contact Plating | Gold |
| Number of Contacts | 14 |
| Connector System | Board-to-Board |
Key Features
- Features 14 contacts arranged in 2 rows with 1.27 mm pitch for precise fitting.
- Constructed with liquid crystal polymer housing for robustness and thermal stability.
- Supports a maximum operating voltage of 340V and current rating of 3.4A.
- Contact material is bronze plated with gold for superior conductivity and corrosion resistance.
- Suitable for straight orientation with solder termination type for surface mount assembly.
- Operating temperature range spans from -55°C to 125°C for varied environmental conditions.
- Dual wipe Tiger Claw™ contact design ensures extended contact life and reliability.
- Applicable for multiple industrial sectors including electronics manufacturing and board-level assemblies.
Product Description
Samtec CLP-107-02-G-D PCB Socket is a high-quality, straight orientation, surface mount socket designed for board-to-board applications requiring precise and reliable connections. Featuring 14 contacts arranged in 2 rows with a 1.27 mm pitch, this socket offers secure and stable electrical contact with a maximum voltage rating of 340V and current carrying capacity of 3.4A. The housing is made from liquid crystal polymer, providing excellent thermal and mechanical stability under demanding conditions.
The contacts employ bronze material with gold plating to ensure superior conductivity and resistance to corrosion, enhancing durability in industrial environments. Its operating temperature range from -55°C to 125°C makes it suitable for a broad spectrum of laboratory, industrial, and manufacturing applications where variable temperatures are common.
One key feature is the dual wipe Tiger Claw™ contact strip which delivers rugged and reliable connections with extended life, safeguarding critical electronic circuits. The socket supports solder termination, ideal for surface mounting on printed circuit boards in electronics production lines.
This product from the CLP series offers versatile connectivity solutions for designers and engineers focused on high precision and long-term reliability. Typical use cases include PCB assemblies in communications equipment, automotive electronics, and industrial control systems.
Features 14 contacts in 2 rows with 1.27 mm pitch for accurate fitment. Durable liquid crystal polymer housing for enhanced mechanical properties. Rated for 340V voltage and 3.4A current capacity. Gold-plated bronze contacts ensure excellent electrical performance.
Wide temperature tolerance from -55°C to 125°C for harsh environments. Dual wipe Tiger Claw™ contact offers extended operational lifespan. Solder termination facilitates surface mount manufacturing processes. Ideal for industrial, manufacturing, laboratory, and electronics assembly applications.
This CLP Series PCB socket exemplifies Samtec’s commitment to robust and reliable connector solutions. Explore more PCB Sockets and electronic components at EnvMart to find compatible accessories and additional connectivity options.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum operating voltage rating of this socket is 340V.
This model has a current rating of 3.4A.
It uses a solder termination type, suitable for surface mount assembly.
The socket features 14 contacts arranged in 2 rows with a pitch of 1.27 mm.
The housing is made from liquid crystal polymer, while the contacts are bronze plated with gold.
The operating temperature range spans from -55°C to 125°C.
This socket has a straight orientation.
It is applicable for various sectors including electronics manufacturing and board-level assemblies.
It features a dual wipe Tiger Claw™ contact design, which ensures extended contact life and reliability.
The socket has 2 rows and a total of 14 contacts.
The country of origin for this socket is the United States.
It supports a board-to-board connector system.
