Cosel DC/DC Converter 12V dc Output, -12 V dc Output, 1.25 A, 24V dc Input Range, 9V Minimum Input, 30 W Power MGFW302412-R
Specifications
| Country of Origin | Japan |
|---|---|
| Voltage | Converters / DC-DC Converters Cosel MGFW DC/DC Converter, 12V dc, -12 V dc/ 1 |
| Brand | Cosel |
| Efficiency | 88% |
| Length | 25.4mm |
| Model | MGFW302412-R |
| Depth | 9.9mm |
| Gross Weight | 40g |
| Width | 9.9mm |
| Mount Type | PCB |
| Series | MGFW |
| Maximum Operating Temperature | 85°C |
| Package Type | DIP |
| Minimum Operating Temperature | -40°C |
| Number of outputs | 2 |
| Ripple and Noise | 150mV Pk-Pk |
| Maximum Output Power | 30W |
| Maximum Input Voltage | 24V dc |
| Standards/Approvals | CE, cUL, cULus, EN 60950-1, TUV, UL 60950-1 |
| Minimum Input Voltage | 9V |
| Number of Pins | 6 |
| Output Voltage 1 | 12, -12V dc |
| Output Current 1 | 1.25A |
| Output Voltage Adjustment Range | 11.765 to 12.492 V |
| Isolation Voltage | 500V dc |
| High reliability | no built-in aluminium and tantalum electrolytic capacitor |
| High efficiency | synchronised rectification circuit (MGS10 / MGS15 / MGFS15 / MGS30 / MGFS30) |
Key Features
- Supports a wide input voltage range from 9 V minimum to 24 V maximum.
- PCB mount package with DIP type and 6 pins for easy integration.
- High efficiency of 88% ensures reduced power losses.
- Designed for industrial applications with an operating temperature range from -40°C to 85°C.
- Provides 500 V dc isolation voltage for safe operation and noise reduction.
- Compact dimensions with length 25.4 mm, width 9.9 mm, and depth 9.9 mm.
- Includes built-in overcurrent and overvoltage protection circuits.
- Features synchronised rectification circuit for enhanced performance.
Product Description
Cosel MGFW302412-R DC/DC Converter is a highly reliable industrial-grade device providing dual output voltages of 12 V dc and -12 V dc. It supports a wide input voltage range from 9 V to 24 V dc which makes it suitable for varied power supply environments.
This converter comes in a compact DIP package with a PCB mounting type facilitating easy installation on printed circuit boards. The unit has a maximum output power of 30 W and delivers output current of 1.25 A. It features a 6-pin configuration optimized for secure electrical connections.
Designed for demanding industrial, electronic components, power supplies, and transformer applications, it can operate over a wide temperature range from -40°C to 85°C. The device provides an isolation voltage of 500 V dc which ensures safety and reduces electrical noise interference between input and output.
The MGFW Series features high efficiency of 88% through synchronised rectification circuits that reduce power losses and heat generation. Additional protections such as built-in overcurrent and overvoltage protection circuits enhance device longevity and safe operation. The unit is compliant with multiple international safety standards including CE, cUL, cULus, EN 60950-1, TUV, and UL 60950-1.
This converter is ideal for integration in industrial, manufacturing, laboratory, and power supply design projects requiring stable and reliable dual DC voltage outputs within compact spaces.
Supports dual output voltages: 12 V dc and -12 V dc. Broad input voltage range from 9 V to 24 V dc. High efficiency with synchronised rectification circuit. Compact DIP package suitable for PCB mounting. Built-in protection circuits for overcurrent and overvoltage.
Wide operating temperature range from -40°C to 85°C. Isolation voltage of 500 V dc enhances safety. Compliant with CE, cUL, and UL safety standards. 6-pin configuration for secure electrical connectivity. Made in Japan, ensuring quality and reliability.
Explore the complete range of DC/DC Converters at EnvMart to find reliable power solutions for your industrial and electronic design needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum output power of this model is 30 W.
It provides dual output voltages of 12 V dc and -12 V dc.
This converter supports a wide input voltage range from 9 V to 24 V dc.
The efficiency rating of the Cosel MGFW302412-R is 88%.
It provides an isolation voltage of 500 V dc, enhancing safety and reducing noise.
The operating temperature range is from -40°C to 85°C.
The dimensions are 25.4 mm in length, 9.9 mm in width, and 9.9 mm in depth.
This model supports PCB mounting with a DIP package type.
Yes, it includes built-in overcurrent and overvoltage protection circuits.
This converter has a 6-pin configuration for secure electrical connections.
It is compliant with CE, cUL, cULus, EN 60950-1, TUV, and UL 60950-1.
The output current is 1.25 A.
