Samtec Straight Surface PCB Header 40 Contacts 0.5 mm Pitch 2 Row Shrouded LSHM-120-02.5-L-DV-A-S-K-TR

Samtec LSHM-120-02.5-L-DV-A-S-K-TR is a premium straight surface mount PCB header designed for high-density, high-speed board-to-board interconnections. It features 40 male contacts arranged in two rows with a fine 0.5 mm pitch, providing compact yet robust connectivity solutions.

The housing is made from Liquid Crystal Polymer, offering excellent mechanical strength and thermal resistance, making it suitable for harsh industrial and commercial environments. The contacts are crafted from phosphor bronze and plated with gold, ensuring low contact resistance and durability over multiple mating cycles.

Operating temperature ranges from -55°C to 125°C, suitable for demanding electronic applications including telecommunications, computing, industrial automation, and instrumentation. Rated for 2 A current and 160 V voltage, it supports a wide range of signal and power transmission needs.

The shrouded design improves alignment during mating and protects against accidental contact, enhancing reliability in assembly lines and field applications. The surface mount termination method facilitates automated soldering processes and reduces assembly time.

The connector is ideal for applications requiring reliable, high-performance board-to-board connections with reduced space footprint. Manufactured in the United States, it meets quality expectations for professional electronic manufacturing.

The connector features 40 male contacts arranged in 2 rows with 0.5 mm pitch for compactness. Constructed with a Liquid Crystal Polymer housing providing mechanical strength and thermal stability. Contacts made of phosphor bronze and plated with gold for excellent conductivity and corrosion resistance.

Designed to operate reliably between -55°C and 125°C temperature range. Supports up to 2 A current and 160 V voltage rating for versatile electronic applications. Surface mount mount type enables easy PCB assembly and secure mechanical fit.

Shrouded design ensures protection and helps prevent misalignment during mating. Board-to-board connector system offering high-speed data and power transmission. Termination type is solder for permanent and reliable connection.

Manufactured in the United States ensuring quality and compliance to industry standards.

This Samtec PCB Header is commonly used across electronic manufacturing industries including telecommunications, computer hardware, industrial control systems, and consumer electronics. Its precision engineering and robust materials provide long service life and consistent performance under various environmental conditions.
