Samtec IPL1 Series Straight Through Hole PCB Header 20 Contacts 2.54 mm Pitch 2 Row Shrouded

Free Delivery in India | Lowest Global Shipping Charges

Samtec IPL1 Series Straight Through Hole PCB Header 20 Contacts 2.54 mm Pitch 2 Row Shrouded

Name: Samtec IPL1 Series Straight Through Hole PCB Header 20 Contacts 2.54 mm Pitch 2 Row Shrouded
Brand: Samtec
SKU: 216040
Price: 3.59 USD
Availability: InStock



Category PCB Header Brand Samtec Condition New

Specifications

Country of Origin	India
Voltage	954V
Brand	Samtec
Orientation	Straight
Current	3.8A
Model	IPL1
Mount Type	Through Hole
Housing Material	Liquid Crystal Polymer
Contact Material	Phosphor Bronze
Series	IPL1
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	2.54mm
Contact Plating	Gold
Number of Contacts	20
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Wire-to-Board

Key Features

Designed for wire-to-board connectivity with a through hole mount type.
Contacts are made from phosphor bronze and plated with gold for durability and reliable connection.
The housing is constructed from liquid crystal polymer offering excellent thermal and mechanical stability.
Rated for current up to 3.8A and voltage up to 954V for robust electrical performance.
Operating temperature range from -55°C to 125°C supports diverse industrial applications.
Shrouded contact system enhances connection security and protection.
Male contact gender termination with solder type ensures secure PCB mounting.
Ideal for electronic components and power connector assemblies in industrial, manufacturing, and electronics applications.

Product Description

Samtec IPL1-110-01-L-D-K Straight Through Hole PCB Header is a precision connector designed for wire-to-board applications with a 20 contact, 2 row shrouded configuration and 2.54 mm pitch.

The connector features phosphor bronze contacts plated with gold to provide superior electrical conductivity and long-lasting durability. Its housing is made from liquid crystal polymer, delivering robust mechanical strength and resistance to environmental stress.

Rated for 3.8A current and 954V voltage, this PCB header supports demanding electronic assemblies with operating temperatures from -55°C to 125°C, making it suitable for use in industrial, scientific, manufacturing, and electronics sectors.

The male contact gender with solder termination type ensures a stable and reliable connection to printed circuit boards via through-hole mounting. Wire-to-board connection system providing versatility in electronic device integration.

Shrouded design to protect contacts and prevent accidental disconnection. Two rows of contacts and 2.54 mm pitch offer compact and efficient PCB layout. Highly durable materials ensure long-term performance and reliability.

Wide temperature range accommodates harsh industrial environments. Supports a current rating suitable for a variety of electrical devices. Utilized in industrial automation, electronics manufacturing, and electrical distribution systems.

This product is new and originates from India by default. It caters to professionals requiring high-quality PCB connectors for robust circuit design implementations. Browse the EnvMart electronics and connectors category for a broad selection of PCB Headers and related components to suit diverse requirements.
