Samtec IPL1 Series Right Angle Through Hole PCB Header 20 Contact 2.54 mm Pitch 2 Row Shrouded IPL1

Samtec IPL1 Series Right Angle Through Hole PCB Header IPL1 is a high-quality, shrouded PCB connector designed for wire-to-board connections requiring durability and electrical reliability. Its 20 male contacts are gold plated over phosphor bronze, housed in liquid crystal polymer which withstands operating temperatures from -55°C to 125°C. The 2-row right angle design with a 2.54 mm pitch supports compact PCB layouts and ensures efficient assembly.

Designed for industrial and manufacturing applications, this through hole mount header supports a current rating of 3.8A and a voltage rating up to 954V, making it suitable for power and signal interfaces in electronic devices, control panels, and instrumentation. The shrouded contacts provide enhanced safety by preventing shorts and physical damage during handling and operation.

The connector is ideal for use in electronics manufacturing, laboratory equipment, automation systems, and commercial electronics requiring robust and reliable PCB header connections. Its solder termination type provides a permanent, secure connection to printed circuit boards, ensuring long lasting performance under mechanical and environmental stress.

Features 20 gold-plated male contacts ensuring reliable electrical connection. Constructed with liquid crystal polymer housing for durability and high temperature resistance. Designed with 2.54 mm pitch and double row configuration for compact PCB mounting.

Rated for 3.8A current and 954V voltage with operation from -55°C to 125°C. Shrouded design enhances contact protection and prevents accidental shorting. Through hole mount type provides secure mechanical stability on PCB.

Contact material utilizes phosphor bronze offering excellent conductivity and strength. Termination type is solder for permanent and stable connection. Manufactured in the United States ensuring quality standards.

This Samtec IPL1 connector provides a dependable solution for electronics engineers and technicians designing compact and reliable circuit interfaces. Browse our selection of PCB Headers and related connectors to find compatible components for your applications at EnvMart.
