Samtec SHF Series Straight Surface PCB Header 10 Contacts 1.27 mm Pitch 2 Row Shrouded SHF-105-01-L-D-SM-LC

Samtec SHF-105-01-L-D-SM-LC is a high-quality SHF series straight surface mount PCB header featuring 10 contacts arranged in 2 rows with a 1.27 mm pitch. This connector is shrouded to provide secure connection and polarization, preventing incorrect mating during assembly.

The housing is made of robust liquid crystal polymer material, offering excellent mechanical strength and thermal resistance. The contacts are made from phosphor bronze with gold plating, providing superior electrical conductivity and long-lasting corrosion resistance.

The connector is intended for surface mounting on printed circuit boards with solder termination type, making it suitable for automated manufacturing and electronic assembly processes. Its straight orientation and male contact gender support various wire-to-board applications.

Operating temperature ranges from -55°C up to 125°C, allowing this component to be used in a wide range of industrial and commercial environments including communications, computing, and embedded electronics.

This PCB header does not carry specific certifications but is engineered for reliability in general electronics manufacturing scenarios. It mates with complementary FFSD/FFTP series connectors without strain relief and features a polarization notch for correct assembly.

Constructed with a liquid crystal polymer housing for durability. Gold plating on phosphor bronze contacts ensures excellent conductivity and corrosion resistance. Designed for solder termination on surface mount applications.

Operates reliably in temperatures ranging from -55°C to 125°C. Male contact gender with 1.27 mm row pitch suitable for wire-to-board connection systems. Shrouded to provide polarization and prevent mis-mating. Meets no specific standards or approvals, designed for general electronic component use.

Ideal for use in electronics manufacturing, PCB assembly, and industrial electronic applications.

This Samtec PCB Header is a dependable component widely used in electronics and electrical industries. It supports high-density board-to-board connections and is optimized for surface mount manufacturing processes. Explore more PCB connectors and headers in the electronics category on EnvMart for your assembly and production needs.
