Samtec SHF Series Straight Surface PCB Header, 10 Contacts, 1.27 mm Pitch, 2 Row, Shrouded SHF-105-01-L-D-TH-TR

Samtec SHF Series SHF-105-01-L-D-TH-TR is a high-quality straight surface PCB Header equipped with 10 contacts in a 2-row, shrouded format. Designed specifically for board-to-wire systems, it features a compact 1.27 mm pitch, making it ideal for space-constrained electronic assemblies.

Provides 10 reliable contacts for electronic signal transmission. Features a 1.27 mm pitch for compact PCB layouts. Shrouded housing ensures accurate mating and protection from misalignment. Surface mount orientation suitable for modern assembly processes.

Constructed with liquid crystal polymer housing for stability and durability. Phosphor bronze contact material, plated with silver and tin for enhanced conductivity. Supports operating temperatures from -55°C to 125°C for robust performance.

Male contact gender and solder termination compatible with automated assembly techniques.

The header’s black LCP insulator and robust contact plating make it suitable for demanding industrial, commercial, and manufacturing applications, including electronics, control panels, instrumentation, and high-density PCB designs. With a solder termination type, the component is optimized for automated soldering processes, ensuring efficiency and precision in mass production environments.

This product is widely adopted for PCB connection solutions in telecommunications, consumer electronics, industrial equipment, laboratory devices, and automotive control modules. Its durability and operational flexibility make it an excellent fit for environments requiring reliable connection performance over an extended temperature range.
