Preci-Dip 5 Way Straight Through Hole 2.54 mm Pitch Socket Contact Carrier 100 V AC, 150 V DC, Solder 712-87-105-41-001101

Preci-Dip 712-87-105-41-001101 is a 5 Way Straight Through Hole Socket Contact Carrier designed for reliable electronic component connections in industrial, manufacturing, and laboratory environments. With a pitch of 2.54 mm, this socket carrier supports mating pin diameters of 0.47 mm. It is ideal for applications requiring precision and durable electrical contacts.

The contacts are made of beryllium copper alloy combined with brass sleeves plated with gold and tin, offering excellent conductivity and corrosion resistance. The housing is constructed from fibreglass reinforced polycyclohexylenedimethylene terephthalate, providing high mechanical strength and thermal resistance. This carrier is suitable for solder mounting on printed circuit boards (PCB), ensuring secure and stable connections.

Electrical ratings include 100 V AC and 150 V DC voltage tolerance with a maximum current rating of 3A, suitable for moderate electrical loads. The product operates efficiently within a wide temperature range from -55°C to 125°C, ensuring dependable performance even in demanding industrial environments.

Compact in size with length 12.7 mm, width 1.83 mm, and depth 4.26 mm, this Preci-Dip socket carrier fits well into dense PCB layouts while maintaining strong connectivity. Manufactured in Switzerland, it meets high-quality standards but does not carry any specific certification marks.

Equipped with 5 contacts for stable electrical connections. Contacts made from beryllium copper alloy and brass for durability. Gold and tin plating ensures excellent conductivity and corrosion resistance. Current rating of 3A suitable for moderate power applications.

Voltage rating of 100 V AC, 150 V DC for reliable operation. Fibreglass reinforced housing offers mechanical strength. Solder termination type provides secure PCB mounting. Wide operating temperature range from -55°C to 125°C.

Compact dimensions ensure space-saving PCB integration. Manufactured in Switzerland with premium quality.

Suitable for use in electronics manufacturing, industrial automation, laboratory test equipment, and other commercial electrical systems. These socket carriers contribute to enhanced production efficiency by supporting easy, reliable PCB integration.
