Amphenol Industrial MIL Spec Circular Connector Copper Alloy Straight 19 Contacts, Male Green Cable PT06E-14-19S(SR)

Free Delivery in India | Lowest Global Shipping Charges

Amphenol Industrial MIL Spec Circular Connector Copper Alloy Straight 19 Contacts, Male Green Cable PT06E-14-19S(SR)

Name: Amphenol Industrial MIL Spec Circular Connector Copper Alloy Straight 19 Contacts, Male Green Cable PT06E-14-19S(SR)
Brand: Amphenol Industrial
SKU: 135039
Price: 65.32 USD
Availability: InStock



Category Mil Spec Circular Connector Brand Amphenol Industrial Condition New

Specifications

Country of Origin	China
Voltage	1kV ac
Brand	Amphenol Industrial
Colour	Green
Orientation	Straight
Model	PT06E-14-19S(SR)
Mount Type	Cable
Housing Material	Aluminium
Contact Material	Copper Alloy
Series	PT
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Contact Plating	Gold
Number of Contacts	19
Contact Gender	Female
Connector Gender	Male
Shell Size	14
Military Standard	MIL-DTL-26482
Mating Type	Bayonet
Connector Size	Miniature
Shell Plating	Cadmium

Key Features

Manufactured with copper alloy contacts plated in gold for superior conductivity.
Features a straight orientation and miniature connector size for compact installations.
Shell size 14 with an aluminium housing and cadmium plating for durability and corrosion resistance.
Rated for voltage up to 1kV AC with a solder termination type to ensure secure contact.
Operating temperature range from -55°C to 125°C for versatile industrial applications.
Bayonet mating type with strain relief and a green color-coded shell for easy identification.
Meets MIL-DTL-26482 military standard for reliable performance in harsh environments.
Male connector gender with female contacts ensuring wide compatibility.

Product Description

Amphenol Industrial PT06E-14-19S(SR) is a Mil Spec Circular Connector designed for cable mounting with a straight orientation and 19 copper alloy female contacts plated in gold. It features a shell size 14 and miniature connector size, housed in aluminium with cadmium plating for enhanced durability and corrosion protection. Rated for 1kV AC voltage, this connector ensures secure and reliable connections in industrial and military applications.

The connector uses a bayonet mating mechanism for quick and secure locking with strain relief to maintain cable integrity. Its operating temperature range spans from -55°C to 125°C, making it suitable for extreme environmental conditions. The green color shell aids in easy identification during installation and maintenance.

Manufactured according to MIL-DTL-26482 military specifications, the PT series connectors are known for their interchangeability and consistent performance. This series offers a wide range of insert arrangements supporting both power and signal contacts from 2 to 61 circuits, with the PT06E-14-19S(SR) model providing a reliable 19-contact configuration.

The gold-plated copper alloy contacts ensure optimal conductivity and long service life. Its aluminium housing with cadmium plating offers excellent mechanical strength and resistance against corrosion, suitable for aviation, defense, industrial equipment, and other applications requiring high reliability.

Manufactured with copper alloy contacts plated in gold for superior conductivity. Features a straight orientation and miniature connector size for compact installations. Shell size 14 with an aluminium housing and cadmium plating for durability and corrosion resistance.

Rated for voltage up to 1kV AC with a solder termination type to ensure secure contact. Operating temperature range from -55°C to 125°C for versatile industrial applications. Bayonet mating type with strain relief and a green color-coded shell for easy identification.

Meets MIL-DTL-26482 military standard for reliable performance in harsh environments. Male connector gender with female contacts ensuring wide compatibility. Ideal for electronics, power, and connector applications in industrial and military settings.

Explore more premium industrial connectors at EnvMart to suit your electronics and power connection requirements.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

The connector is rated for a voltage of up to 1kV AC, ensuring it can handle high voltage applications effectively.

It features copper alloy contacts plated in gold for superior conductivity, and an aluminium housing with cadmium plating for durability and corrosion resistance.

The operating temperature range for this connector spans from -55°C to 125°C, making it suitable for extreme environmental conditions.

This model has 19 female contacts, allowing for a reliable connection in various applications.

It uses a solder termination type to ensure secure contact, which is essential for reliable connections in demanding environments.

The connector has a shell size of 14, which is part of its design for compact installations.

It features a bayonet mating type, which allows for quick and secure locking during installation.

Yes, it meets the MIL-DTL-26482 military standard, ensuring reliable performance in harsh environments.

The shell of this connector is green, which aids in easy identification during installation and maintenance.

This model has a male connector gender with female contacts, ensuring wide compatibility with various systems.

It is designed for industrial and military applications, particularly in environments requiring high reliability and durability.

This connector is classified as a miniature connector, which is suitable for compact installations.
