Amphenol Communications Solutions EconoStik Series Right Angle Through Hole Pin Header 2 Contacts 2.54 mm 10129379-902003BLF

Amphenol Communications Solutions 10129379-902003BLF is a right angle through hole pin header from the EconoStik Series designed for demanding electronic applications requiring robust and precise PCB interconnections. It features 2 contacts with a 2.54 mm pitch that is widely compatible with standard board layouts, providing flexibility in industrial, commercial, and testing environments.

The header utilizes a high-temperature thermoplastic housing which provides resistance to environmental challenges while maintaining structural integrity. Its brass contacts are plated with 1μin gold, ensuring excellent electrical conductivity and corrosion resistance, capable of withstanding repeated mating cycles up to 50 times.

This connector supports currents up to 3 amperes and voltages as high as 1500 volts, making it suitable for power and signal transmission in compact board-to-board systems. The unshrouded design facilitates easy access and inspection of contact points during assembly.

The component is terminated by soldering through-hole mount style, guaranteeing a secure and durable attachment to PCBs. It operates within a temperature range from -55°C to 105°C, allowing use in diverse environments from cold storage equipment to heated industrial chambers.

Typical applications include industrial control units, test equipment, metering devices, POS terminals, set-top boxes, surveillance systems, and vending machines. The 8.08 mm mating pin length enhances mechanical stability and reliable electrical connection.

Features a right angle orientation for compact PCB designs. Constructed with thermoplastic housing for high temperature resistance. Brass contacts plated with 1μin gold to ensure superior conductivity and corrosion resistance.

Supports a maximum current rating of 3A and voltage up to 1500V. Designed for through hole mounting with solder termination for secure board attachment. Unshrouded design allows easy mating and inspection. Operates reliably between -55°C and 105°C for varied environmental applications.

Contact mating pin length of 8.08 mm for strong mechanical and electrical connection. Suitable for industrial control, metering, POS machines, surveillance, and test equipment applications.

This high-quality PCB header from Amphenol Communications Solutions embodies durability and performance, ideal for electronics manufacturers and developers seeking dependable connectors. Explore more in the PCB Headers category on EnvMart for related components and accessories.
