Nexperia 40 V 5 A Low Forward Voltage Schottky Diode Surface Mount SOD-128 PMEG4050ETP,115
Specifications
| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Height | 1.1mm |
| Length | 4mm |
| Model | PMEG4050ETP,115 |
| Width | 2.7mm |
| Mount Type | Surface |
| Maximum Operating Temperature | 175°C |
| Package Type | SOD-128 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 5A |
| Peak Reverse Repetitive Voltage Vrrm | 40V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 42mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 70A |
| Maximum Forward Voltage Vf | 490mV |
| Average forward current | IF(AV) ≤ 5 A |
| Reverse voltage | VR ≤ 40 V |
Key Features
- Low forward voltage of 490 mV enables efficient power use.
- High surge current tolerance of 70 A peak non-repetitive forward surge current.
- Wide operating temperature range from -55°C to 175°C for reliability.
- Compact 4 mm × 2.7 mm × 1.1 mm SOD-128 package enables space saving on PCBs.
- AEC-Q101 qualified for automotive applications ensuring high quality standards.
- Single diode configuration with 2 pins for easy surface mount installation.
- Reverse leakage current of 42 mA at peak reverse voltage.
- Advanced clip-bonding technology provides high power capability and stress protection.
Product Description
Nexperia PMEG4050ETP,115 is a high-performance Schottky diode designed for efficient power rectification with a maximum continuous forward current of 5 A and a peak reverse voltage of 40 V. It features a low forward voltage drop of 490 mV which minimizes power dissipation and improves efficiency in circuits.
Encapsulated in a compact SOD-128 surface mount package measuring 4 mm in length, 2.7 mm in width, and 1.1 mm in height, this diode is ideal for applications requiring space saving on densely populated printed circuit boards. The device supports a wide operating temperature from -55°C up to 175°C, allowing usage in demanding automotive and industrial environments.
The PMEG4050ETP,115 is qualified to automotive AEC-Q101 standards, ensuring robust performance and reliability under stress conditions. The diode's integrated guard ring provides additional stress protection, enhancing durability in high-current scenarios.
This Schottky diode is well suited for applications including power management, voltage clamping, battery charging circuits, and general-purpose rectification where low forward voltage and fast switching are essential. Its single diode configuration and 2-pin layout facilitate straightforward surface mounting and integration into compact electronic assemblies.
Low forward voltage of 490 mV enables efficient power use. High surge current tolerance of 70 A peak non-repetitive forward surge current. Wide operating temperature range from -55°C to 175°C for reliability. Compact 4 mm × 2.7 mm × 1.1 mm SOD-128 package enables space saving on PCBs.
AEC-Q101 qualified for automotive applications ensuring high quality standards. Single diode configuration with 2 pins for easy surface mount installation. Reverse leakage current of 42 mA at peak reverse voltage. Advanced clip-bonding technology provides high power capability and stress protection.
Ideal for power management, battery charging, and voltage clamping applications. Explore the Nexperia Schottky Diode range and related semiconductor products in EnvMart electronics components for reliable, high-performance power solutions.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current for the PMEG4050ETP,115 is 5 A.
This model has a peak reverse voltage rating of 40 V.
The forward voltage drop for this diode is 490 mV.
The SOD-128 package measures 4 mm in length, 2.7 mm in width, and 1.1 mm in height.
The operating temperature range for this model is from -55°C to 175°C.
The diode can tolerate a peak non-repetitive forward surge current of 70 A.
Yes, it is qualified to the AEC-Q101 automotive standard, ensuring high quality standards.
This diode supports surface mounting with a single diode configuration and 2 pins.
The reverse leakage current at peak reverse voltage is 42 mA.
It is suitable for applications including power management, voltage clamping, and battery charging circuits.
The diode utilizes advanced clip-bonding technology, providing high power capability and stress protection.
This model is a Schottky rectifier type diode.
