Hirose DF3 Series Right Angle Through Hole PCB Header, 2 Contacts, 2 mm Pitch, 1 Row, Shrouded DF3A-2P-2DS

Hirose DF3A-2P-2DS is a right angle through hole PCB Header connector from the DF3 series with a 2 mm contact pitch and 2 contacts arranged in a single row. It is designed for precision and reliability in electronic component assemblies requiring board-to-board or wire-to-board connections. This shrouded header ensures enhanced mechanical protection and contact safety.

The connector housing is made of durable polyamide material providing excellent insulation and mechanical strength, suitable for industrial electronic applications. Contacts are copper alloy plated with tin to assure long-lasting and stable electrical conductivity. The product supports a continuous current of up to 3A and voltage ratings up to 250V, making it reliable for low voltage circuits.

Operating temperature ranges from -30°C to 85°C, allowing for use in diverse environments including commercial, industrial, and laboratory electronics. The through hole mounting system with solder termination type facilitates robust mechanical mounting onto PCBs, enhancing assembly strength and reliability.

Right angle orientation aids in compact PCB designs and routing efficiency. The shrouded one-row configuration offers protection against accidental contact or shorts, optimizing safety in densely populated electronic assemblies. Each unit is manufactured in Japan, reflecting high quality and consistent standards.

Constructed with polyamide housing for durability and insulation. Supports a maximum current rating of 3A and voltage rating of 250V. Features tin plating on copper alloy contacts for reliable connectivity. Designed for through hole mounting with solder termination type.

Operates reliably between -30°C to 85°C temperature range. Connector system supports board-to-board and wire-to-board applications. Compact right angle orientation optimizes PCB layout and space. Shrouded design protects contacts and improves safety during handling.

Manufactured in Japan ensuring high workmanship standards.

This Hirose DF3 series header is recommended for industrial, electronic manufacturing, laboratory instrumentation, and commercial electronic applications requiring secure, space-efficient PCB connectivity solutions. Browse our Electronics & Electricals categories for more Hirose connectors and PCB components.
