TDK Chassis Mount EMC Filter 10 A 250V AC/DC 50Hz, 60 Hz Single Phase B84113H0000B110

Free Delivery in India | Lowest Global Shipping Charges

TDK Chassis Mount EMC Filter 10 A 250V AC/DC 50Hz, 60 Hz Single Phase B84113H0000B110



Category EMC Filter Brand TDK Condition New

Specifications

Country of Origin	China
Brand	TDK
Height	43mm
Length	52mm
Model	B84113H0000B110
Depth	117.5mm
Mount Type	Chassis Mount
Operating Frequency	50, 60Hz
Series	B84113H
Maximum Operating Temperature	100°C
Number Of Stages	2
Capacitance	2pF
Minimum Operating Temperature	-25°C
Maximum Current	10A
Number of Phases	1
Leakage Current	369μA
Maximum Voltage	250V ac/dc
Inductance	4mH
Standards/Approvals	UL 1283
Termination Style	Tab

Key Features

Designed for high insertion loss applications in switched mode power supplies.
Compact and easy to install chassis mount design with tab termination.
Low leakage current of 369 microamperes ensures energy efficiency.
Operating temperature range from -25°C to 100°C suitable for harsh environments.
Constructed with a polyurethane potting material rated UL 94 V-0 for robustness and safety.
Complies with UL 1283 standard for EMI filters ensuring reliable performance.
Inductance of 4 millihenries and capacitance of 2 picofarads suited for noise suppression.

Product Description

TDK B84113H0000B110 is a single phase chassis mount EMC filter designed to provide effective electromagnetic interference (EMI) suppression in electronic and electrical equipment. It operates reliably with a maximum current of 10 A and supports AC/DC voltages up to 250 V at frequencies of 50 Hz and 60 Hz.

This EMC Filter is engineered for use in switched mode power supplies commonly found in telecom and data systems, delivering very high insertion loss to ensure stable and noise-free operation. The filter features a two-stage design combined with an inductance of 4 mH and a capacitance of 2 pF to effectively mitigate conducted emissions.

The compact housing measures 52 mm in length, 43 mm in height, and 117.5 mm in depth, with a chassis mount type allowing easy installation. Its termination style uses tab connectors, enabling a secure 1-phase connection while facilitating quick assembly.

Designed to operate between -25°C and 100°C, the filter retains low leakage current of 369 µA, contributing to overall energy efficiency. The polyurethane potting material conforms to UL 94 V-0 flammability standards, enhancing the durability and safety of the filter in harsh operating environments.

This product is certified to meet the UL 1283 standard and comes from a manufacturing origin in China. It is ideal for industrial, telecommunications, and commercial electronic applications requiring stringent EMI suppression with dependable performance.

Compact chassis mount design with tab termination for ease of installation. Low leakage current and high insertion loss for superior EMI suppression. Durable polyurethane potting material ensures safety and longevity. Wide operating temperature range suitable for various industrial environments.

UL 1283 compliance guarantees international safety and quality standards. Explore more EMC and power line filter solutions to improve the reliability and compliance of your electronic equipment at EnvMart.
