Vishay 1.68 V Zener Diode, Single 500 mW Power Dissipation, 5% Tolerance, Surface Mount 2-Pin SOD-80 TZMC6V8-GS08

Free Delivery in India | Lowest Global Shipping Charges

Vishay 1.68 V Zener Diode, Single 500 mW Power Dissipation, 5% Tolerance, Surface Mount 2-Pin SOD-80 TZMC6V8-GS08

Name: Vishay 1.68 V Zener Diode, Single 500 mW Power Dissipation, 5% Tolerance, Surface Mount 2-Pin SOD-80 TZMC6V8-GS08
Brand: Vishay
SKU: 214102
Price: 0.04 USD
Availability: InStock



Category Zener Diodes Brand Vishay Condition New

Specifications

Country of Origin	India
Brand	Vishay
Length	3.7mm
Model	TZMC6V8-GS08
Mount Type	Surface
Series	TZM
Maximum Operating Temperature	175°C
Package Type	SOD-80
Minimum Operating Temperature	-65°C
Standards/Approvals	RoHS
Pin Count	2
Number of Elements per Chip	1
Automotive Standard	AEC-Q101
Maximum Power Dissipation Pd	500mW
Diode Configuration	Single
Test Current It	5mA
Maximum Reverse Leakage Current	10μA
Nominal Zener Voltage Vz	6.8V
Zener Type	Voltage Regulator
Maximum Zener Impedance	150Ω

Key Features

This diode features a voltage regulator Zener type with a 5% voltage tolerance.
Surface mount type with a compact 2-pin SOD-80 package, suitable for SMT applications.
Maximum test current is rated at 5 mA ensuring stable performance.
Operates across a wide temperature range from -65°C to 175°C, meeting AEC-Q101 automotive standards.
Maximum forward and reverse leakage currents are minimal, ensuring low power loss.
The device has a maximum Zener impedance of 150 Ω at the test current.
RoHS compliant ensuring environmentally safe manufacturing.
Suitable for electronic circuits requiring voltage regulation and protection applications.

Product Description

Vishay TZMC6V8-GS08 is a high-quality single Zener diode designed for voltage regulation applications, providing a nominal Zener voltage of 6.8 V and power dissipation up to 500 mW in a compact SOD-80 surface mount package.

This diode is built for reliable performance with a voltage tolerance of ±5%, ensuring stable voltage regulation in sensitive electronic circuits. It features a surface mount design with 2 pins, optimizing it for automated assembly and space-constrained printed circuit boards in modern electronic devices.

Test current is set at 5 mA, and the diode's maximum Zener impedance is 150 Ω, balancing performance and efficiency. The device withstands operating temperatures from -65°C to 175°C, making it suitable for automotive and industrial environments compliant with the AEC-Q101 automotive standard.

Additional benefits include low reverse leakage current of 10 μA, and the diode is RoHS compliant, supporting eco-friendly production. Ideal for use in power supplies, voltage reference circuits, and protection circuitry in electronic manufacturing, industrial equipment, and automotive electronics.

This diode features a voltage regulator Zener type with a 5% voltage tolerance. Surface mount type with a compact 2-pin SOD-80 package, suitable for SMT applications. Maximum test current is rated at 5 mA ensuring stable performance.

Operates across a wide temperature range from -65°C to 175°C, meeting AEC-Q101 automotive standards. Maximum forward and reverse leakage currents are minimal, ensuring low power loss. The device has a maximum Zener impedance of 150 Ω at the test current.

Length of the diode body measures approximately 3.7 mm, compact for tight PCB layouts. RoHS compliant ensuring environmentally safe manufacturing. Suitable for electronic circuits requiring voltage regulation and protection applications.
