JAE Right Angle Through Hole PCB Header 7 Contacts 2.5 mm Pitch 1 Row Shrouded IL-AG5-7P-S3L2

Free Delivery in India | Lowest Global Shipping Charges

JAE Right Angle Through Hole PCB Header 7 Contacts 2.5 mm Pitch 1 Row Shrouded IL-AG5-7P-S3L2



Category PCB Header Brand JAE Condition New

Specifications

Country of Origin	India
Brand	JAE
Orientation	Right Angle
Current	3A
Model	IL-AG5-7P-S3L2
Mount Type	Through Hole
Housing Material	Polybutylene Terephthalate
Contact Material	Brass
Series	IL-AG5
Termination Type	Solder
Maximum Operating Temperature	85°C
Minimum Operating Temperature	-40°C
Number of Rows	1
Pitch	2.5mm
Contact Plating	Tin
Number of Contacts	7
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Wire-to-Board

Key Features

Features a 7-contact configuration for secure electrical connections.
2.5 mm pitch with one row ensures compact PCB mounting.
Housing constructed from durable polybutylene terephthalate material.
Right angle orientation facilitating flexible PCB design layout.
Shrouded design prevents accidental mismating and provides mechanical lock.
Contacts made of brass with tin plating for reliable conductivity.
Supports maximum current rating of 3A, suitable for moderate power applications.
Designed for through hole mounting with solder termination type.

Product Description

JAE IL-AG5-7P-S3L2 Right Angle Through Hole PCB Header, equipped with 7 male contacts in a single row with 2.5 mm pitch, is engineered for robust and reliable PCB connections in automotive and electronic instrument panel applications.

Constructed with a polybutylene terephthalate housing, this header features a shrouded design with a mechanical lock mechanism to ensure positive mating and prevent dislodging of contacts during vibrations or mechanical stresses.

The brass contacts are tin plated for enhanced conductivity and corrosion resistance. The right angle orientation allows for flexible PCB layouts suitable for complex circuit designs.

This header is rated for a continuous current of 3 amperes and supports operating temperatures between -40°C and 85°C, making it suitable for automotive and industrial environments.

Termination is through-hole with soldering ensuring strong electrical and mechanical connections. The connector system supports wire-to-board interface, facilitating ease of assembly in manufacturing processes.

7-contact configuration for secure and reliable PCB connectivity. 2.5 mm pitch and single-row layout optimize space on circuit boards. Durable polybutylene terephthalate housing for mechanical strength and heat resistance.

Shrouded with mechanical lock to prevent mismating and contact dislodgement. Brass contacts with tin plating ensure reliable electrical performance. Right angle orientation for versatile PCB design and integration. Rated for 3A current and operational in wide temperature ranges (-40°C to 85°C).

Through hole mounting with solder termination type for stable fix to PCB. This product is ideal for use in automotive instrument panels, electronics manufacturing, and other industrial applications requiring dependable PCB connections.

Explore more high-quality PCB Header solutions by JAE and other reputable brands on EnvMart.

Looking to purchase in bulk?

Purchase item in bulk quantity
Get best price for your business

Comments (0)

No customer reviews for the moment.

Frequently Asked Questions

This model is rated for a maximum continuous current of 3A, making it suitable for moderate power applications.

The contacts of this header are configured with a pitch size of 2.5 mm, allowing for compact PCB mounting.

It features a total of 7 male contacts arranged in a single row.

The housing is constructed from polybutylene terephthalate, which provides mechanical strength and heat resistance.

This PCB header utilizes a solder termination type, ensuring a stable fix to the PCB during assembly.

It operates effectively within a temperature range of -40°C to 85°C, making it suitable for various environments.

The shrouded design of this model includes a mechanical lock mechanism that prevents accidental mismating and dislodging of contacts.

It supports a wire-to-board connector system, facilitating ease of assembly in manufacturing processes.

This model has a right angle orientation, which allows for flexible PCB design layouts.

The contacts are made of brass and are tin plated to enhance conductivity and corrosion resistance.

The product is manufactured in India.

The shrouded design not only prevents accidental mismating but also provides a mechanical lock to secure the connection during vibrations or mechanical stresses.
