JAE Automotive Connector Female Yellow Cable 16 Way Crimp Termination IL-AG5-16P-D3C1

The JAE IL-AG5-16P-D3C1 Automotive Connector is a female socket housing connector specifically engineered for automotive electrical systems. It features a 16-contact configuration arranged in two rows, providing a compact and robust connection interface suitable for cable mounting.

This connector series is recognized for its high reliability in demanding automotive environments, with a polybutylene terephthalate housing that offers excellent mechanical strength and environmental resistance. The tin-plated contacts facilitate secure, corrosion-resistant electrical connections.

The crimp termination ensures efficient assembly and reliable connectivity. Designed to function within operating temperatures from -40°C up to 85°C, it meets stringent automotive requirements including mechanical locking to prevent unmating and double locking mechanisms that secure contacts within the housing.

Its yellow housing color enables quick identification within wiring harness assemblies, aiding maintenance and troubleshooting. The compact form factor with dimensions approximately 33.8 mm in height, 34.8 mm in width, and 34.8 mm in depth fits typical instrument panel space constraints.

This product is ideal for automotive manufacturers and electrical harness assemblers who require a dependable connector solution for instrument panel applications, ensuring optimum mechanical and electrical performance.

Features 16 contacts in two rows for versatile wiring configurations. Polybutylene terephthalate housing ensures durability and insulation. Crimp termination type provides secure connectivity. Operates reliably between -40°C and 85°C.

Yellow housing for easy identification. Compact size: 33.8mm height, 34.8mm width, 34.8mm depth. Tin-plated contacts resist corrosion and improve conductivity. Mechanical double lock prevents dislodging of contacts. Designed for automotive instrument panel wiring harnesses.

Supports 3A current per contact for electrical loads. Explore the wide range of Automotive Connectors available at EnvMart to meet your industrial and manufacturing needs.
