JAE Automotive Connector Female Yellow 16-Way Crimp Termination Cable Socket Housing IL-AG5-16P-D3C1
Specifications
| Country of Origin | India |
|---|---|
| Brand | JAE |
| Colour | Yellow |
| Current | 3A |
| Height | 33.8mm |
| Model | IL-AG5-16P-D3C1 |
| Depth | 34.8mm |
| Width | 34.8mm |
| Gender | Female |
| Mount Type | Cable |
| Housing Material | Polybutylene Terephthalate |
| Series | IL-AG5 |
| Termination Type | Crimp |
| Maximum Operating Temperature | 85°C |
| Sub Type | Socket Housing |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 690-9843Brand: JAEManufacturers Part No.: IL-AG5-16P-D3C1 |
| Contact Plating | Tin |
| Number of Contacts | 16 |
Key Features
- Features a dual-row socket housing with 16 contacts for reliable connections.
- Constructed with polybutylene terephthalate housing material ensuring durability.
- Contact plating utilizes tin to protect against corrosion and ensure conductivity.
- Rated for 3A current capacity with operating temperatures from -40°C to 85°C.
- Includes a mechanical lock and double lock mechanism to prevent dislodging and mismating.
- Designed for automotive instrument panels with high reliability socket contacts.
- Yellow color coding aids in identification and wiring organization.
- Simplified crimp-type termination supports efficient assembly processes.
Product Description
JAE IL-AG5-16P-D3C1 automotive connector female is a yellow, 16-way socket housing designed for cable mounting with crimp termination. It belongs to the IL-AG5 series of automotive connectors and is engineered specifically for automotive instrument panel applications.
The connector features a dual-row design with 16 socket contacts plated with tin for superior conductivity and corrosion resistance. Its housing is manufactured from high-quality polybutylene terephthalate, providing mechanical strength and resistance to temperature extremes, with an operating range from -40°C to 85°C.
This product includes a mechanical lock that assures positive mating and a double lock mechanism that prevents contact dislodging, increasing reliability in demanding automotive environments. The unique housing configuration prevents mismating, ensuring proper assembly and connection integrity.
Termination is by crimp type, allowing simplified and effective cable assembly. Although no cord is included, this female connector is suitable for integration with flexible cables in automotive electrical systems. The yellow color helps in easy identification and wiring management within instrument panels.
Ideal for industrial automotive electrical applications, this connector supports consistent performance in harsh environments, making it suitable for automotive manufacturing, repair, and maintenance activities.
Features a dual-row socket housing with 16 contacts for reliable connections. Constructed with polybutylene terephthalate housing material ensuring durability. Contact plating utilizes tin to protect against corrosion and ensure conductivity.
Rated for 3A current capacity with operating temperatures from -40°C to 85°C. Includes a mechanical lock and double lock mechanism to prevent dislodging and mismating. Designed for automotive instrument panels with high reliability socket contacts.
Yellow color coding aids in identification and wiring organization. Simplified crimp-type termination supports efficient assembly processes. No cord included; cable mounting type connectors suitable for various flexible cables.
