onsemi Operational Amplifier 2.2 MHz 8-Pin SOIC Surface Mount 13V MC33202DR2G

onsemi MC33202DR2G is a dual operational amplifier with 2.2 MHz gain bandwidth product packaged in an 8-pin SOIC surface mount format designed for versatile electronic component applications.

This Op Amp supports single supply voltage operation from 3V up to 13V and features rail-to-rail input and output capability allowing the output to swing within 50 mV of either supply rail. This functionality eliminates phase reversal even with inputs extending 200 mV beyond the supply rails, which enhances signal integrity in sensitive circuits.

The device provides excellent performance with a typical slew rate of 1 V/μs and output current capacity of 80 mA. Such attributes make it well-suited for audio applications and other instrumentation where low noise, high output drive capability, and rapid signal response are critical.

Designed to operate reliably over a broad temperature range from -40°C to 105°C and conforming to both RoHS compliance and the automotive grade AEC-Q100 standard, the MC33202DR2G ensures quality and durability in industrial, automotive, manufacturing, and laboratory environments.

Key features include a low input bias current of 200 nA and an input offset voltage of 8 mV that help minimize distortion. The compact height (1.5 mm), width (4 mm), and length (5 mm) of its SOIC package facilitate ease of integration in space-constrained designs.

Features rail-to-rail input and output voltage capabilities ensuring maximum dynamic range. Operates on low supply voltage as low as 3V and up to a maximum of 13V. Provides a high slew rate of 1 V/μs and gain bandwidth product of 2.2 MHz for fast signal processing.

Capable of delivering output currents up to 80 mA making it suitable for high drive applications. Low input bias current of 200 nA and input offset voltage of 8 mV minimizes signal distortion. Operating temperature range is wide, from -40°C to 105°C ensuring reliability in various environments.

Compliant with RoHS standards and meets the automotive AEC-Q100 standard for quality assurance.

This operational amplifier is ideal for use in electronic circuit design applications including industrial automation, audio signal processing, automotive electronics, and precision instrumentation.

EnvMart offers the onsemi MC33202DR2G Operational Amplifier as part of its high-quality semiconductor components for professional and industrial use.
