Taiwan Semiconductor Schottky Diode 3-Pin SOT-23 70 V 70 mA BAS70-04 RF

Taiwan Semiconductor BAS70-04 RF is a 3-pin SOT-23 packaged Schottky diode engineered for reliable and efficient operation in electronic circuits requiring low forward voltage and fast switching.

This Schottky diode features a maximum continuous forward current of 70 mA and can withstand peak reverse repetitive voltages up to 70 V. It boasts a low forward voltage of 1 V to minimize power losses, along with an extremely low peak reverse current of 100 nA, making it highly efficient in diode rectification and switching scenarios.

Designed for surface mount applications, the SOT-23 package measures 3.05 mm in length, 1.4 mm in width, and 0.95 mm in height, enabling compact and space-saving PCB layouts suitable for electronics manufacturing including telecommunications, power management, and consumer electronics.

The diode operates reliably across a wide temperature range from -55°C to 125°C, supporting industrial and commercial temperature requirements. Its fast peak reverse recovery time of 5 ns allows for high-speed switching capabilities critical in frequency-sensitive circuits.

Additional robustness is provided by its capability to handle a peak non-repetitive forward surge current of 100 A, which protects against brief current spikes that can occur during power surges or startups.

Surface mount SOT-23 package. Maximum continuous forward current: 70 mA. Peak reverse voltage: 70 V. Forward voltage drop: 1 V. Peak reverse current: 100 nA. Operating temperature range: -55°C to 125°C. Peak reverse recovery time: 5 ns.

Peak surge current: 100 A non-repetitive. This diode is ideal for use in electronic component applications including power rectification, switching, and protection in industrial, laboratory, and consumer electronics. Explore more semiconductor products and Schottky Diodes at EnvMart to meet your electronic design and manufacturing needs.
