HARWIN M20 Series Straight Surface Pin Header 8 Contact 2.54 mm Pitch 1 Row Unshrouded M20-8770842

HARWIN M20-8770842 is a straight surface mount PCB pin header connector featuring 8 contacts arranged in a single row with 2.54 mm pitch. It is unshrouded with male brass contacts plated in gold for enhanced conductivity and corrosion resistance.

The housing is made of nylon thermoplastic designed to withstand high temperatures involved in reflow soldering processes, ensuring reliability in manufacturing. It supports board-to-board and wire-to-board connector systems, with a mating pin length of 5.8 mm for stable mechanical and electrical connection.

Rated for a current carrying capacity of 3 amperes, the connector operates reliably within a temperature range of -40°C to 105°C. The straight orientation and unshrouded design provide flexibility for various embedded electronic and industrial applications including consumer electronics, communications, drives, controls, and personal computing devices.

The M20 series headers are versatile with options for dual or single row configurations and mating pin length variations. The castellated housing design allows trimming to size when needed, though caution is advised when cutting tails.

This pin header enables robust electrical connections in compact PCB layouts. High temperature nylon housing facilitates surface mount reflow solder compatibility. Gold-plated brass contacts maintain low contact resistance and longevity.

Unshrouded male pins ease connection to corresponding PCB sockets and jumpers. The connector is suitable for industrial, commercial, and consumer electronics applications. Manufactured to industrial standards in Taiwan Province of China ensuring consistent quality.

Choose HARWIN M20-8770842 for reliable, high-quality PCB Pin Header solutions in demanding electronic designs and assembly processes. Explore a wide range of connectors and electronic components at EnvMart to support your design and manufacturing needs.
