Weidmüller LU Series PCB Terminal Block 5-Contact 10 mm Pitch Through Hole 1 Row 2453720000
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | 1kV |
| Brand | Weidmüller |
| Colour | Black |
| Current | 92A |
| Length | 26.4mm |
| Depth | 47.03mm |
| Width | 51.5mm |
| Mount Type | Through Hole |
| Series | LU |
| Number of Rows | 1 |
| Pitch | 10mm |
| Standards/Approvals | cURus, RoHS, UL |
| Number of Contacts | 5 |
| Minimum Wire Size mm² | 0.5mm² |
| Maximum Wire Size mm² | 25mm² |
| Minimum Wire Size AWG | 18AWG |
| Maximum Wire Size AWG | 6AWG |
| Wire Connection Method | Push-in |
Key Features
- Supports conductor cross-sections up to 25 mm² for versatile wiring.
- Push-in wire connection method enables fast and tool-free installation.
- Includes integrated test points for safe and easy inspection.
- Constructed with high-quality WEMID insulating material to enhance derating reserves.
- Compact dimensions of 26.4 mm length, 51.5 mm width, and 47.03 mm depth.
- Single row configuration with 5 contacts suited for PCB applications.
- Complies with cURus, RoHS, and UL standards ensuring safety and reliability.
Product Description
Weidmüller 2453720000 LU Series PCB Terminal Block is a high-performance connector designed for printed circuit board (PCB) applications requiring secure and efficient electrical connections. Featuring 5 contacts with a 10 mm pitch, this terminal block supports through-hole mounting and is built to accommodate conductor cross-sections ranging from 0.5 mm² to 25 mm², making it suitable for a wide range of wire sizes including 18 AWG to 6 AWG.
The product incorporates a push-in connection method, enabling fast and tool-free wire connections while ensuring a secure clamp for reliable contact. An integrated test point supports inspection using PS 2.0 test plugs or test probes, facilitating safe maintenance and troubleshooting operations. The contact points remain securely clamped due to the "Connection Safety Concept" inherent in the design.
The terminal block is constructed using WEMID insulating material, which increases derating reserves for enhanced electrical performance under various conditions. It offers a voltage rating of 1 kV and a current capacity of 92 A, making it suitable for demanding industrial and electronic applications.
Dimensions of the terminal block measure 26.4 mm in length, 51.5 mm width, and 47.03 mm depth, and the product features a single row configuration with 5 contacts. The black color housing is compliant with international standards including cURus, RoHS, and UL, ensuring high safety and environmental performance.
This PCB terminal block is ideal for use in various industries including industrial electronics, power connectors, control cabinets, and manufacturing where reliable electrical connection and durability are critical. The through-hole mounting technology ensures robust physical attachment to PCBs for mechanical stability.
Push-in wire connection method for fast installation. Supports wire sizes from 0.5 mm² to 25 mm². Voltage rating of 1 kV with 92 A current capacity. Integrated test points for safe testing. Compliance with cURus, RoHS, and UL standards.
Compact size for efficient PCB space utilization. Single-row 5-contact terminal configuration. Explore the full range of Weidmüller PCB Terminal Blocks and connectors on EnvMart for professional industrial applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The terminal block has a voltage rating of 1 kV, making it suitable for various industrial and electronic applications.
It has a current capacity of 92 A, allowing it to handle substantial electrical loads.
This model supports conductor cross-sections ranging from 0.5 mm² to 25 mm², equivalent to wire sizes from 18 AWG to 6 AWG.
The contacts are arranged with a pitch of 10 mm, which is standard for many PCB applications.
It utilizes a push-in wire connection method, allowing for fast and tool-free installation.
The terminal block measures 26.4 mm in length, 51.5 mm in width, and 47.03 mm in depth.
It complies with cURus, RoHS, and UL standards, ensuring safety and environmental performance.
This model features a single row configuration with 5 contacts.
The terminal block is manufactured in Germany.
The housing of this terminal block is black in color.
It is designed for through-hole mounting, ensuring robust physical attachment to PCBs.
Yes, it includes integrated test points for safe inspection using PS 2.0 test plugs or test probes.
