Weidmüller LU Series PCB Terminal Block 4-Contact 10 mm Pitch Through Hole 1 Row 2453710000
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 1kV |
| Brand | Weidmüller |
| Colour | Black |
| Current | 92A |
| Length | 41.5mm |
| Depth | 26.4mm |
| Width | 47.03mm |
| Mount Type | Through Hole |
| Series | LU |
| Number of Rows | 1 |
| Pitch | 10mm |
| Standards/Approvals | cURus, RoHS, UL |
| Number of Contacts | 4 |
| Minimum Wire Size mm² | 0.5mm² |
| Maximum Wire Size mm² | 25mm² |
| Minimum Wire Size AWG | 18AWG |
| Maximum Wire Size AWG | 6AWG |
| Wire Connection Method | Push-in |
Key Features
- High current rating of 92A supports demanding applications.
- Push-in connection method provides quick and tool-free conductor installation.
- Supports wire sizes from 0.5 mm² to 25 mm² for versatile wiring options.
- Constructed with black color insulating material for durability and safety.
- Designed for through-hole mounting on PCBs with 1 row configuration.
- Meets standards including cURus, RoHS, and UL for quality assurance.
Product Description
Weidmüller 2453710000 LU Series PCB Terminal Block is a robust electronic connector designed for PCB mounting with a through-hole solder connection. It features 4 contact points arranged in a single row with a 10 mm pitch, making it suitable for various industrial and commercial electrical applications. The terminal block supports conductor cross sections from 0.5 mm² to 25 mm² using a convenient push-in connection system that allows quick, reliable, and tool-free wiring.
The terminal block has a high current carrying capacity of 92 amperes and a voltage rating up to 1kV, ensuring secure and efficient electrical connections in demanding environments. The assembly is made using WEMID insulating material, increasing derating reserves for enhanced thermal and electrical reliability. Its black coloration aids in clear identification and safety compliance.
Additional features include integrated test points located centrally on the upper side for easy electrical testing with PS 2.0 test plugs, supporting maintenance and troubleshooting. The LU series connector complies with industry standards such as cURus, RoHS, and UL, demonstrating adherence to safety and environmental regulations.
This PCB terminal block is ideal for applications in industrial control systems, automation equipment, manufacturing plants, and electrical panel building. Its construction and reliability make it well-suited for electronics, power connector assembly, and instrumentation where secure, high-current PCB connections are essential.
High current rating of 92A supports demanding applications. Push-in connection method provides quick and tool-free conductor installation. Supports wire sizes from 0.5 mm² to 25 mm² for versatile wiring options. Constructed with black insulating material for durability and safety.
Through-hole mounting design enables stable PCB attachment. Integrated test points facilitate easy electrical testing. Meets cURus, RoHS, and UL standards for quality and safety. Explore more high-quality PCB Terminal Blocks and connectors at EnvMart to meet diverse industrial and electronics assembly requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a high current rating of 92A, making it suitable for demanding applications.
It has a voltage rating of up to 1kV, ensuring secure electrical connections in various applications.
It supports wire sizes ranging from 0.5 mm² to 25 mm², providing versatile wiring options.
The contacts are arranged with a pitch of 10 mm, suitable for standard PCB layouts.
This unit utilizes a push-in connection method, allowing for quick and tool-free conductor installation.
The dimensions are 41.5 mm in length, 26.4 mm in depth, and 47.03 mm in width.
It features 4 contacts arranged in a single row configuration.
It meets several standards including cURus, RoHS, and UL, ensuring quality and safety compliance.
This model is designed for through-hole mounting on PCBs, providing stable attachment.
Yes, it includes integrated test points on the upper side for easy electrical testing with PS 2.0 test plugs.
The country of origin for this terminal block is China.
It is ideal for use in industrial control systems, automation equipment, manufacturing plants, and electrical panel building.
