Weidmüller OMNIMATE SL Series Pluggable Terminal Block 4-Contact 5.08 mm Pitch 1 Row 1780200000
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | 400V |
| Brand | Weidmüller |
| Colour | Black |
| Orientation | Right Angle |
| Current | 19A |
| Length | 11.6mm |
| Depth | 12mm |
| Width | 22.22mm |
| Housing Material | Glass Filled Liquid Crystal Polymer |
| Series | OMNIMATE SL |
| Number of Rows | 1 |
| Pitch | 5.08mm |
| Number of Contacts | 4 |
| Connector Gender | Male |
| Wire Connection Method | Solder |
Key Features
- The housing is made of glass-filled liquid crystal polymer for high temperature resistance.
- Supports a current rating of 19 A and voltage rating of 400 V.
- The connector is male gender with right angle orientation, suitable for SMT mount on PCB.
- The terminal block width is 22.22 mm with a length of 11.6 mm and depth of 12 mm.
- Designed for solder wire connection providing robust electrical contact.
- Polarising pins ensure correct mating and prevent mismatch connections.
- Ideal for industrial electronic components and power connector applications on SMT boards.
- Manufactured in Germany under the OMNIMATE SL series.
Product Description
Weidmüller 1780200000 OMNIMATE SL Series Pluggable Terminal Block is a high-quality 4-contact connector designed for demanding electronic applications requiring robust and reliable wire-to-board connections. Featuring a 5.08 mm pitch and a single-row configuration, this terminal block is crafted from glass-filled liquid crystal polymer, offering excellent thermal and mechanical stability suitable for wave or reflow soldering processes.
The connector is male gender with a right angle orientation, optimized for SMT boards with a pin length of 3.2 mm to ensure mechanical and electrical integrity. Its compact dimensions - 22.22 mm width, 11.6 mm length, and 12 mm depth - allow efficient PCB space utilization.
Operating at a current rating of 19 A and voltage up to 400 V, this terminal block supports a wide range of industrial electronic and power connector uses. The solder wire connection method and the incorporation of polarizing pins enhance assembly reliability and ensure correct mating with corresponding cable mount terminals.
The OMNIMATE SL series leverages advanced connector technologies such as leaf spring clamp and rising clamp screw mechanisms, facilitating secure, vibration-resistant connections for industrial, manufacturing, HVAC, and laboratory electrical systems.
The housing material provides exceptional resistance to high temperatures encountered in wave or reflow soldering. Polarising pins prevent connection mismatches, enhancing safety and reliability. Adaptable to various PCB designs with right-angle SMT mounting.
Manufactured with precision in Germany ensuring top-quality standards. Suitable for electronics assembly in industrial, construction, and automation environments.
For mating cable mount terminals, compatible stock numbers include those designed for screw, rising clamp, and tension clamp screwless types, facilitating flexible configuration choices for your electrical assembly needs.
Discover the comprehensive range of Weidmüller Pluggable Terminal Blocks on EnvMart to equip your projects with trusted connectivity solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a current rating of 19 A and a voltage rating of 400 V.
The pitch size of this terminal block is 5.08 mm.
It has a width of 22.22 mm, a length of 11.6 mm, and a depth of 12 mm.
This terminal block uses a solder wire connection method.
The connector has a right angle orientation, making it suitable for SMT mounting on PCBs.
The housing is made of glass-filled liquid crystal polymer, providing high temperature resistance.
This model features 4 contacts.
Yes, it is designed for industrial electronic components and power connector applications on SMT boards.
It is manufactured in Germany.
The incorporation of polarising pins ensures correct mating and prevents mismatched connections, enhancing reliability.
It is compatible with cable mount terminals designed for screw, rising clamp, and tension clamp screwless types.
This terminal block is part of the OMNIMATE SL series.
