Weidmüller BL Series Pluggable Terminal Block, 14 Contacts, 3.5 mm Pitch, 1 Row, 300V, Female, Polybutylene 1597480000

The Weidmüller BL Series model 1597480000 is a pluggable terminal block engineered to deliver reliable wire-to-board connections in industrial and electronic applications. Featuring 14 contacts and a 3.5 mm pitch, this terminal block ensures precise and secure integration into PCB layouts. Its robust polybutylene terephthalate (PBT) housing is rated UL94 V-0 for flammability, supporting safety and performance needs.

This Pluggable Terminal Block is specially designed with a horizontal wire entry, using a clamping yoke terminal mechanism. The product accommodates a broad range of wire sizes, from 0.08 mm² to 1.5 mm² and 28 AWG to 14 AWG, facilitating versatility in wiring. The female connector gender promotes compatibility with matching male headers, and its 180° orientation ensures straightforward alignment during assembly.

Rated for a maximum current of 10A and voltage up to 300V, the block is suitable for demanding environments where reliable electrical performance is paramount. The space-saving design contributes to compact PCB assemblies, ideal for both industrial and laboratory electronics. The orange housing colour aids in visual identification and maintenance, while the product’s width (49 mm) and depth (18.5 mm) provide a balance between density and accessibility.

Applications include signal and power distribution within electronic assemblies, industrial automation, HVAC systems, manufacturing controls, and general commercial wiring solutions. The Omnimate series supports cost-effective, space-efficient PCB connection methods with vertical or horizontal solder headers.

Key features include straightforward clamping, compatibility with tension clamp or screw terminal harnesses, and polarising pins for prevention of mismatched connections. The terminal block's performance is backed by rigorous construction standards and material quality for long-term use.
